35 BA0 BLUE ODD DATA SIGNAL 0
36 BA1 BLUE ODD DATA SIGNAL 1
4.1.6 CON8: VGA TERMINAL
Pin # Signal Name Function
1 SCL-DDC DDC DATA CLOCK Line (SCL)
2 GND GROUND
3 VSYNC V-SYNC
4 HSYNC H-Sync
5 GND Ground
6 SDA-DDC DDC SERIAL DATA LINE (SDA)
7 VCC-DDC Green Video Ground
8 GND GROUND
9 GND GROUND
10 BLUE Blue Video
11 GND Ground
12 GREEN GREEN VIDEO
13 GND Ground
14 RED RED VIDEO
4.1.7 CON12: SPEAKER Connector
Pin # Signal Name Function
1 RIGHT-P RIGHT POSITIVE (VOLUME INCREASE_
2 RIGHT-M RIGHT MINUS (VOLUME DECREASE)
3 LEFT-P LEFT POSITIVE (VOLUME INCREASE_
4 LEFT-M LEFT MINUS (VOLUME DECREASE)
ViewSonic Corporation
25
Confidential --Do Not Copy VE150m/mb
