ViewSonic VE150M - Page 42

MECHANICAL PARTS LIST
ViewSonic Corporation
38
Confidential --Do Not Copy VE150m/mb
ITEM
NO.
VIEWSONIC P/N REFERENCE NUMBER DESCRIPTION QTY
1
C-FP-0301-0774 FFA-VE150-1010 PLASTIC,LCD,FRONT BEZEL-FUNCTION BUTTON-LENS-ASS'Y,VE150S-AA 1
2
M-LCD-0826-0151 LCD-M150X3T-41 PANEL LCD,M150X3-T03,CMO 15",TRADITIONAL PANE (TN+FILM) 1
3
M-SCW-0824-0730 SR0-50113-0080 SCREW-MM-BND-NI-3*8 4
4
M-WR-0828-0674 WIL-VE150-LC31 WIRE-ASS'Y,M/B-LCD,60P-(30P+26P),CMO,MRT V,JHEN VEI,VE150M-M 1
5
PL-PD-0714-0079 RUB-VE150-1010 RUBBER FOOT,W13*L20*T10mm,VE150M-M 1
6
B-SB-0221-0504 IVC-150X3-0473 INVERTER,M150X3-T03,CMO 15",7PIN 180°,4LAMP(1L),DAC-12C043,DELTA,VE150M-M 1
7
B-MB-0201-0727 PMF-151MV-0101 ASS'Y PCB FINAL,M/B (MRT/Mascot V),V10,CMO,FOR VIEWSONIC,VE150M-M 1
8
M-SCW-0824-0534 SR0-50153-0060 SCREW-MM-BND-ZNC-3*6 6
9
M-SCW-0824-0541 SR1-50113-0100 SCREW-TB-BND-NI-3*10 11
10 INS-VE150-1060 INSULATION,INVERTER,VE150M-M 1
11 BRA-VE150-1080 METAL,LCD,BRACKET,FRAME,CMO 15",VE150M-M 1
12
A-VC-0101-0288 CAB-VE150-VG31 CABLE VGA,PC99,200CM,H89B42B4,15P-14P,W/SR,JHEN VEI,VE150M-M 1
13
M-SCW-0824-0731 SR1-31153-0060 SCREW-TB-RON-STW-ZNC-3*6 1
14
B-SB-0221-0325 PSF-VE150-0201 ASS'Y PCB FINAL,S/B,V20,VE150X-AA 1
15
M-SCW-0824-0543 SR1-50154-0100 SCREW-TB-BND-ZNC-4*10 4
16
M-MS-0808-6838 BRA-VE150-1030 METAL,LCD,BASE HINGE,VE150S-AA 1
17
C-BC-0302-0471 FFA-VE150-1050 PLASTIC,LCD,REAR BEZEL-LOCK PLATE-ASS'Y,CMO 15",MADE IN CHINA,VE150M-M 1
18
M-MS-0808-6840 BRA-VE150-1050 METAL,LCD,LOCK PLATE,VE150S-AA/VE150L-AA 1
19
E-SK-0412-0068 SPK-VE150-1050 SPEAKER,4.0 OHM,2W,D40*20,R340*L140mm,FG-40N020A4,FORTUN,VE150M-M 1
20
M-SCW-0824-0537 SR1-00122-0060 SCREW-TB-PAN-BK-2*6 4
21
M-CV-0830-0238 COV-VE150-1050 PLASTIC,LCD,VESA COVER,VE150S-AA/VE150L-AA 1
22
M-CV-0830-0239 COV-VE150-1060 PLASTIC,LCD,CABLE COVER,VE150S-AA/VE150L-AA 1
23
M-MS-0808-6843 BRF-VE150-3011 METAL,STAND BOTTOM PLATE-ASS'Y,REV1,VE150S-AA/VE150L-AA 1
24
PL-PS-0715-0176 COV-VE150-3031 PLASTIC,STAND BASE,VE150S-AA 1
25
M-CV-0830-2282 COV-VE150-3010 PLASTIC,STAND FRONT TOP,VE150S-AA 1
26
M-CV-0830-2283 COV-VE150-3020 PLASTIC,STAND BEAR TOP,VE150S-AA 1
27
M-SCW-0824-0539 SR1-30153-0060 SCREW-TB-RON-ZNC-3*6 4
28
M-MS-0808-6863 HIN-VE150-1010 METAL,STAND,HINGE R,VE150S-AA/VE150L-AA 1
29
M-MS-0808-6864 HIN-VE150-1020 METAL,STAND,HINGE L,VE150S-AA/VE150L-AA 1
30
M-SCW-0824-0535 SR0-52153-0080 SCREW-MM-BND-SPW-ZNC-3*8 6
31
M-SCW-0824-0534 SR0-50153-0060 SCREW-MM-BND-ZNC-3*8 4
32
M-SCW-0824-0538 SR1-10113-0080 SCREW-TB-FLT-NI-3*8 4
33
M-MS-0808-7236 RUB-IY151-1503 RUBBER FOOT,D15*t3.0mm 2
