 Mounting your PC to a monitor
1. Secure the VESA mounting kit to your monitor with four screws.
Figure 8 VESA mounting (1)
NOTE
To fasten the mounting bracket your monitor must have VESA75 or
VESA100 standard holes. The VESA mounting kit is optional..
2. Place the VOT125 on the VESA mounting bracket.
3. Make sure the air vents are hooked by the VESA mounting bracket and
VOT125 is solidly secured to the display.
Figure 9 VESA mounting (2)
