ViewSonic VOT133 - Bottom View

3
1-3 Back Side View
1-4 Bottom View
No. Name Description
1 RF(Radio Frequency) Port Connects to antenna
2 USB 2.0 Ports Connects to USB devices
3 DVI Port Connects to display device
4 HDMI Port Connects to HDMI audio and video
5 Network Port Standard RJ-45 network port
6 Line Out and S/PDIF Out Port Connects to powered analog speakers or record-
ing devices with optical connectors(3.5mm jack)
7 Power Input Port Connects to the power adapter
1 3 5
4
76
2
No. Name Description
1 Sheet Metal Magnetic metal feet can be used for connection to optional
VDD100 CD/DVD RW drive
There are four Magnet-Metal-Feet in the package. Just align them to the sheet metal
on the bottom, then they can magnetize the PC Mini easily. The feet can seat and
protect PC Mini when it is placed on the tabletop.
C
A
U
T
I
O
N
!
