Introduction
PC Mini features all the desktop capabilities but with a slim body design which enables you to
browse the internet in a relaxable and comfortable way.
1-1 Top View
1-2 Front Side View
190mm
135mm
1
2
3 764 5
24mm
No. Name Description
1 Headphone Port Connects to a headphone
2
Microphone In and S/PDIF In
Port
Connects to a microphone or playback devices with
optical connectors(3.5mm jack)
3 Multi-Function Card Reader Support SD/SDHC/MS/MS Pro/MMC memory cards
4 USB 3.0 Ports Connect to USB devices
Caution: Before using it, you need to install the “AS-
Media USB3.0 driver” in the Driver CD.
5 HDD_LED Indicates hard disk states
6 Suspend Button Enter suspend mode in operating system
7 Power Button with
Integrated LED Indicator
Turning the power on/off, Indicates system states
