ViewSonic Confidential Creation Date: 09/29/05
Item ViewSonic P/N Ref. P/N Description Location Universal number# Q'ty
61 N/A
5E.0DV01.M01 CHIP CAP 10U 16V Z0805L Y5V
C2 C112
2
62 N/A
5E.0DV01.M01 CHIP CAP C 27P 50V J0603 NPO
C20 C21
2
63 N/A
5E.0DV01.M01 CHIP CAP 47P 50V J0603 NPO
C16 C17 C27 C28
4
64 N/A
5E.0DV01.M01 CHIP CAP C 0.047U25V K0603 X7R
C61
1
65 N/A
5E.0DV01.M01 XTAL 14.31818MHZ 18PF 50PPM
Y1
1
66 N/A
5E.0DV01.M01 DIODE SW BAV70 75V SOT-23
DN5 DN7
2
67 N/A
5E.0DV01.M01 DIODE SW 0.215A75V BAV99 SOT23
DN2 DN3 DN4 DN6 DN8 DN9
DN10 DN11 DN12 DN13 DN14
11
68 N/A
5E.0DV01.M01 DIODE ZEN BZV55C6V2 500MW SOD8
D1 D2 D3 D4 D5 D6 D7 D8 D9
ZD1 ZD2 ZD3 ZD6 ZD7
14
69 N/A
5E.0DV01.M01 XTOR 2N3904S SOT-23 NPN
Q1 Q7 Q8 Q9
4
70 N/A
5E.0DV01.M01 XTOR 2N3906S SOT-23 PNP
Q3
1
71 N/A
5E.0DV01.M01 FET MOS AO4411 30V PC SON-8P
Q6
1
72 B-00008898
5E.0DV02.001 IC V.R. KA431AZTA TO-92T 3P
IC702
1
73 B-00008898
5E.0DV02.001 IC PWM CURRENT NCP1203P60G 8P
IC601
1
74 B-00008898
5E.0DV02.001 IC TRANSITION CTRL L6562N 8P
IC651
1
75 B-00008898
5E.0DV02.001 IC OPTO LTV-817M-A DIP 4P
IC652 IC602
2
76 B-00008898
5E.0DV02.001 DIODE REC 3A600V 1N5406 DO-201
D651
1
77 B-00008898
5E.0DV02.001 CAP DISC Y13300P250VFKC10 L3.5
C615 C603 C604
3
78 B-00008898
5E.0DV02.001 CAP150U450V RC1.1A BC7.5 45*18
C605
1
79 B-00008898
5E.0DV02.001 CAP EL 470U 35V RC1220 CC5 5K
C711 C712 C713 C714
4
80 B-00008898
5E.0DV02.001 CAP PP 0.001U 630V J FKC5
C607
1
81 B-00008898
5E.0DV02.001 CAP X 0.22U U/V/FI 275V RF15
C601
1
82 B-00008898
5E.0DV02.001 CAP MKP 0.47U 520V J RF15
C617 C618
2
83 B-00008898
5E.0DV02.001 RES MOFM 68K J 2W AKF15 MINI
R607
1
84 B-00008898
5E.0DV02.001 RES MOFM 0.22 J 2W AKF15 MINI
R615 R670
2
85 B-00008898
5E.0DV02.001 THERM NTC 5 OHM D16.5 RF7.5
TR601
1
86 B-00008898
5E.0DV02.001 XFORM PWR RM-10 390UH 2405FPW
T651
1
87 B-00008898
5E.0DV02.001 XFORM 600UH DS4020 2407WFP
T601
1
88 B-00008898
5E.0DV02.001 CHOK COIL 300UH T60-26 2405FPW
L609
1
89 B-00008898
5E.0DV02.001 LINE FILTER 11MH ET24 2007FPB
L601
1
90 B-00008898
5E.0DV02.001 LINE FILTER 500UH 18*12 2407WF
L608
1
91 B-00008898
5E.0DV02.001 SKT AC I/O 10A 250V ST-01CP-BA
CN601
1
92 B-00008898
5E.0DV02.001 TVS 10D 470V TVR10471KSC3F7SW
VAR1
1
93 B-00008898
5E.0DV02.001 FUSE4A250V CERA ST20 T/LA RF25
F601
1
94 B-00008898
5E.0DV02.001 HEAD ML 1R3P(-1#2) ST 1S L9.4
CN602
1
95 B-00008898
5E.0DV02.001 HEAD ML 2R12P RT D2 4S H5/2.7
CN702
1
96 B-00008898
5E.0DV02.001 SOLDER BAR SAC300
4.4
97 B-00008898
5E.0DV02.001 PCBA SPS BD SMD VP2650W
1
98 B-00008898
5E.0DV02.001 WIRE 10/9P 1007#24 20MM VX2640
CN701
1
99 B-00008898
5E.0DV02.001 ASSY HSK +GSIB4A60 2408WFP
BD601
1
100 B-00008898
5E.0DV02.001 ASSY HSK+2SK3502+YG971 2408WFP
Q651 D652
2
101 B-00008898
5E.0DV02.001 ASSY HSK+MBRF20H200*2 2408WFP
D701 D703
2
102 B-00008898
5E.0DV02.001 ASSY HSK+2SK3548-01 VX2640W
Q601
1
103 N/A
5E.0DV02.A01 SCR MCR100-6RLRA 400V0.8ATO-92
IC603
1
104 N/A
5E.0DV02.A01 DIODE FAST EGP10D 200V 1A
D602
1
105 N/A
5E.0DV02.A01 DIODE FAST UF4007 1KV 1A
D601 D611
2
106 N/A
5E.0DV02.A01 CAP MONO 0.1U 50V K X7R RT5
C716
1
107 N/A
5E.0DV02.A01 CAP EL 1U 100V M RT5 5*11
C622
1
108 N/A
5E.0DV02.A01 CAP EL47U50V M RT5 6.3*13
C606 C611
2
109 N/A
5E.0DV02.A01 RES MGF 10K J 1/4W AT
R603
1
110 N/A
5E.0DV02.A01 RES MGF 1M 1/4W F AT
R608 R609 R657 R658 R660 R661
6
111 N/A
5E.0DV02.A01 RES MGF 1M 1/2W F AT
R601
1
112 N/A
5E.0DV02.A01 RES MGF 1.2M 1/4W F AT
R604 R605
2
113 N/A
5E.0DV02.A01 RES MGF 499K 1/4W F AT
R671
1
114 N/A
5E.0DV02.A01 BEAD 1/2T D3.5*4.5 TR-22-RH-03
L610 L611 L612 L613
4
115 N/A
5E.0DV02.A01 FUSE 5A32V PICO UR/CSA BEL/MS
F701
1
116 N/A
5E.0DV02.A01 LBL ART 25*4.5 ALL
1
117 N/A
5E.0DV02.A01 PCB SPS BD FR4 VX2640W
1
118 N/A
5E.0DV02.M01 GLUE ADHES PD955 PRH
0.045
119 N/A
5E.0DV02.M01 PCBA SPS BD AI VP2650W
1
120 N/A
5E.0DV02.M01 CHIP RES 100 J 1/4W 1206
R627
1
121 N/A
5E.0DV02.M01 CHIP RES 1K J 1/8W 0805
R613 R669 R677 R714
4
122 N/A
5E.0DV02.M01 CHIP RES 10K J 1/8W 0805
R620 R621 R622 R624 R625 R655
R656 R675 R676 R678 R713
11
123 N/A
5E.0DV02.M01 RES CHIP 100K J 1/8W 0805
R617 R626
2
124 N/A
5E.0DV02.M01 CHIP RES 150 J 1/4W 1206
R611
1
125 N/A
5E.0DV02.M01 CHIP RES 18K J 1/8W 0805
R610 R614 R619
3
126 N/A
5E.0DV02.M01 CHIP RES 2K J 1/8W 0805
R712
1
127 N/A
5E.0DV02.M01 CHIP RES 30 J 1/8W 0805
R668
1
128 N/A
5E.0DV02.M01 CHIP RES 33 J 1/4W 1206
R707 R706 R705
3
129 N/A
5E.0DV02.M01 CHIP RES 47 J 1/8W 0805
R612 R665
2
130 N/A
5E.0DV02.M01 CHIP RES 4.7 J 1/8W 0805
R623
1
131 N/A
5E.0DV02.M01 CHIP RES 68K J 1/8W 0805
R667
1
ViewSonic Corporation
Confidential - Do Not Copy VP2650wb-1
82
