ViewSonic Confidential Creation Date: 09/29/05
Item ViewSonic P/N Ref. P/N Description Location Universal number# Q'ty
132 N/A
5E.0DV02.M01 CHIP RES 150K F 1/8W 0805
R606
1
133 N/A
5E.0DV02.M01 CHIP RES 20K F 1/8W 0805
R659
1
134 N/A
5E.0DV02.M01 CHIP RES 205K F 1/8W 0805
R663
1
135 N/A
5E.0DV02.M01 CHIP RES 22.6K F 1/8W 0805
R666
1
136 N/A
5E.0DV02.M01 CHIP RES 232K F 1/4W 1206
R672 R673
2
137 N/A
5E.0DV02.M01 CHIP RES 28K F 1/10W 0603
R716
1
138 N/A
5E.0DV02.M01 CHIP RES 3.01K F 1/8W 0805
R664
1
139 N/A
5E.0DV02.M01 CHIP RES 3.24K F 1/10W 0603
R715
1
140 N/A
5E.0DV02.M01 CHIP RES 511K F 1/4W 1206
R662
1
141 N/A
5E.0DV02.M01 CHIP RES 8.25K F 1/8W 0805
R674
1
142 N/A
5E.0DV02.M01 CHIP CAP C 1000P 50V K0805 X7R
C609 C610
2
143 N/A
5E.0DV02.M01 CHIP CAP C 0.01U50V K0805S X7R
C621
1
144 N/A
5E.0DV02.M01 CHIP CAP 0.1U 25V K0603 X7R
C612 C613 C625 C629 C630
5
145 N/A
5E.0DV02.M01 CHIP CAP C 0.1U 50V K0603 X7R
C614
1
146 N/A
5E.0DV02.M01 CHIP CAP C 1U 16V K0805L X7R
C627 C628
2
147 N/A
5E.0DV02.M01 CHIP CAP C 1U 25V K1206E X7R
C620
1
148 N/A
5E.0DV02.M01 CHIP CAP 2200P 100V K0805M X7R
C709 C710
2
149 N/A
5E.0DV02.M01 CHIP CAP C 2.2U 10V K0805L X7R
C623 C624
2
150 N/A
5E.0DV02.M01 CHIP CAP C 470P 50V K0805S X7R
C626
1
151 N/A
5E.0DV02.M01 DIODE SW 75V LL4148 SOD-80
D603 D604 D605 D655 D607
5
152 N/A
5E.0DV02.M01 DIODE ZEN BZV55C15 500MW SOD80
ZD601
1
153 N/A
5E.0DV02.M01 DIODE REC 1A200V ES1D-E3 DO214
D606
1
154 N/A
5E.0DV02.M01 DIODE ZEN BZV55C24 500MW SOD80
ZD602 ZD652
2
155 N/A
5E.0DV02.M01 DIODE ZEN 27V 500MW TZMC SOD80
ZD603
1
156 N/A
5E.0DV02.M01 XTOR 2N3904S SOT-23 NPN
Q603 Q656
2
157 N/A
5E.0DV02.M01 XTOR 2N3906S SOT-23 PNP
Q602 Q654
2
158 N/A
5E.0DV02.M01 FET MOS 2N7002K-T1-E3 60V NC
Q653
1
159 B-00008899
5E.0DV07.001 CAP 220U25V RC730 RF3.5 8*12
C5 C6 C15 C16
4
160 B-00008899
5E.0DV07.001 CAP220U35V RC760CC3.5 8*16 4K
C4 C14
2
161 B-00008899
5E.0DV07.001 CHOKE 47UH T50-52 17*10
L1 L2
2
162 B-00008899
5E.0DV07.001 HEAD ML 1R9P ST D2 3S H6
J1
1
163 B-00008899
5E.0DV07.001 SOLDER BAR SAC300
0.4
164 B-00008899
5E.0DV07.001 PCBA TRANSMITTER BDSMD VP2650W
1
165 N/A
5E.0DV07.M01 LBL ART 25*4.5 ALL
1
166 N/A
5E.0DV07.M01 PCB TRANSMITTER BD FR4 VX2640W
1
167 N/A
5E.0DV07.M01 CHIP RES 100 J 1/10W 0603
R1
1
168 N/A
5E.0DV07.M01 CHIP RES 15K J 1/10W 0603
R13 R23
2
169 N/A
5E.0DV07.M01 CHIP RES 20K J 1/10W 0603
R3 R18
2
170 N/A
5E.0DV07.M01 CHIP RES 22 J 1/10W 0603
R7 R19
2
171 N/A
5E.0DV07.M01 CHIP RES 2.7K J 1/10W 0603
R16 R27
2
172 N/A
5E.0DV07.M01 CHIP RES 330 J 1/8W 0805
R15
1
173 N/A
5E.0DV07.M01 CHIP RES 3.3K J 1/10W 0603
R2 R17
2
174 N/A
5E.0DV07.M01 CHIP RES 47K J 1/10W 0603
R14 R24
2
175 N/A
5E.0DV07.M01 CHIP RES 75K J 1/10W 0603
R4 R21
2
176 N/A
5E.0DV07.M01 CHIP RES 1K F 1/10W 0603
R11 R25
2
177 N/A
5E.0DV07.M01 CHIP RES 10K F 1/10W 0603
R6 R9 R22 R26 R28
5
178 N/A
5E.0DV07.M01 CHIP RES 1.69K F 1/10W 0603
R20
1
179 N/A
5E.0DV07.M01 CHIP RES 3.01K F 1/10W 0603
R5
1
180 N/A
5E.0DV07.M01 IC PWM CTRL TL1451ACNS SOP 16P
U1
1
181 N/A
5E.0DV07.M01 CHIP CAP 100P 50V J0603 NPO
C12 C20
2
182 N/A
5E.0DV07.M01 CHIP CAP 0.01U 50V K0603 X7R
C11
1
183 N/A
5E.0DV07.M01 CHIP CAP 0.1U 25V K0603 X7R
C1 C2 C3
3
184 N/A
5E.0DV07.M01 CHIP CAP C 1U 50V Z0805L Y5V
C7 C13 C17
3
185 N/A
5E.0DV07.M01 CHIP CAP C 0.22U 16V K0603 X7R
C8 C18
2
186 N/A
5E.0DV07.M01 CHIP CAP C 680P 50V J0603 NPO
C19
1
187 N/A
5E.0DV07.M01 CHIP CAP C 6800P 50V K0603 X7R
C9 C21
2
188 N/A
5E.0DV07.M01 DIODE SR 2A40V SS24-E3 DO-214A
FD1 FD2 FD3 FD4
4
189 N/A
5E.0DV07.M01 DIODE ZEN TZMC3V9 500MW SOD80
D2
1
190 N/A
5E.0DV07.M01 DIODE ZEN 6.2V 1/2W TZMC6V2
D1
1
191 N/A
5E.0DV07.M01 FET MOS 2SJ598-ZK-E1-AZ TO-252
Q2 Q6
2
192 N/A
5E.0DV07.M01 XTOR 2N3904S SOT-23 NPN
Q1 Q5
2
193 N/A
5E.0DV07.M01 XTOR 2N3906S SOT-23 PNP
Q4 Q7
2
194 B-00008900
5E.0DV15.001 CAP EL 10U 25V M RF2 5*11
C10 C12
2
195 B-00008900
5E.0DV15.001 CAP EL 100U 25V M RF2.5 6.3*11
C13 C14 C23 C24
4
196 B-00008900
5E.0DV15.001 CAP220U35V RC760CC3.5 8*16 4K
C3
1
197 B-00008900
5E.0DV15.001 CAP 220U25VRC640 CC3.5 8*16 5K
C4 C5
2
198 B-00008900
5E.0DV15.001 CHOKE 47UH T50-52 17*10+PCB
L1
1
199 B-00008900
5E.0DV15.001 SKT USB A 2R8P RT UAR64-8K5J00
J5 J6
2
200 B-00008900
5E.0DV15.001 SKT USB2.0 B RT4P UBR24-4K5J00
J4
1
201 B-00008900
5E.0DV15.001 HEAD ML 1R9P ST D2 3S H6
J2
1
202 B-00008900
5E.0DV15.001 SOLDER BAR SAC300
0.4
203 B-00008900
5E.0DV15.001 PCBA USB BD SMD VP2650W CPT
1
204 N/A
5E.0DV15.M01 CONN FPC 7PD1RTH1.9 JS-1157DR
J1
1
205 N/A
5E.0DV15.M01 SOLDER PASTE LF310
0.62
ViewSonic Corporation
Confidential - Do Not Copy VP2650wb-1
83
