ViewSonic Model Number: VS10725
Rev: 1a
Serial No. Prefix: QCK
Item ViewSonic P/N Ref. P/N Description Location Universal number# Q'ty
1 C-00005327 2024272902P FRONT BEZEL GCABA2369T8F---- PS-7604B 1F01 1
2 N/A 2053756001P LED INDIC.-PWR HDECP2012TSF VP930 1F02 1
3 N/A 2044269102P FUNCTION KEY JKNBP2392T8F----PS-7604B 1F03 1
4 N/A 2051353800P NAME PLATE VIEWSONIC BIRD LOGO H:8MM 1F04 1
5 N/A 2071979700P METAL FITTG LANGF2227T8 VP930B 1F16 1
6 N/A 2071881300P BRACKET,FIX LANGF2232T8 VP930B 1F17 2
7 N/A 2082630042P SCREW M3*4 P=0.5 1F18 4
8 N/A 2082630042P SCREW M3*4 P=0.5 1F19 7
9 N/A 2080006500P SCREW,SPE XBMSB30P05000-- (M3*5) VP930B 1F20 4
10 N/A 2080006300P SCREW,SPE LBOSM1069DB VP930B 1F22 6
11 N/A 2061456300P BUSHING PCUSG1687T8 VP930B 1F23 3
12 N/A 2082640082P SCREW M4*8MM P=0.5 1F24 1
13 N/A 2061456400P BUSHING PCUSG1651T8--- 1F25 2
14 N/A 2061456500P BUSHING PISLS1177d8---- 1F26 1
15 N/A 2072461300P INSULATOR PISLV0262T8---- 1F27 1
16 N/A 2072458300P INSULATOR 12*10*1.5 94V0 ADHESIVE 1F28 1
17 N/A 2072461400P INSULATOR 12*10*1.0 94V0 ADHESIVE 1F29 1
18 N/A 2081440082P SCREW,(WASH) M4X8 P=0.7(TOOTH WASHER) 1F30 1
19 C-00005328 2022267502P CABI BACK GCABB1883T8F---- BLK 2C01 1
20 C-00005326 2022267402P CABI BACK GC0VD2626T8F---- BLK 2C02 1
21 N/A 2080006200P SCREW,SPE XBMSB30P06000 VP930B 2C03 4
22 N/A 2071881200P BRACKET,FIX LANGF206-3D8---B VP930B 2C04 1
23 N/A 2071881100P BRACKET,FIX LANGF2194T8---A VP930 2C07 4
24 N/A 2061456100P BUSHING PCUSG1647T8 VP930B 2C08 2
25 N/A 2061456200P BUSHING PCUSG1674T8 VP930B 2C09 1
26 PL-00005315 2028262002P STAND GSTN-27957T8K----BLK 5B01 1
27 N/A 2080006100P SCREW,SPE XBPSB40P10JS0 (M4*10) VP930B 5B02 4
28 P-00008025 2013054023P POLYETHY BAG 160*140MM T=0.5MM LDPE 5B03 2
29 P-00005321 2011091102P CARTON BOX VP930-2 VS10725 TCO03 6P01 1
30 N/A 2055670082P LABEL VP930-3 VS10725(E) AUO 6P02 1
31 N/A 2055613441P LABEL VIEWSONIC 8ms STICKER 89X58mm 6P04 2
32 N/A 2055690045P LABEL VP930-3 VS10725 SMALL LABEL 6P05 1
33 N/A 2055690013P LABEL EnergyStar Sticker 11*11mm 6P06 1
34 M-LB-0813-0856 2055613379P LABEL VIEWSONIC CONTAINER LABEL 6P11 0.071
35 N/A 2055690014P LABEL VP930 H1-POT TLAB-5657T8 6P13 1
36 N/A 2055690015P LABEL VP930 HIGHVOLTAGE TLABZ4916T8 6P14 1
37 P-00005322 2012186700P POLYFOAM SPAKA6617T8F VP930B 6P20 1
38 N/A 2063302400P PROTECTOR PISL-1351T8 VP930B 6P23 1
39 N/A 2055170060P LABEL VP930-2 VS10725 TCO03 6P50 1
40 M-LB-0813-0002 2056603050P SERIAL LABEL VIEWSONIC LCD SERIAL LABEL 6P51 1
41 M-LB-0813-0528 2055103400P LABEL JK0936F WEN 6P52 1
42 P-00008026 2013054030P POLYETHY BAG VP930 LCD BAG SSAKH1356D8-T-B 6P60 1
43 DC-00008034 2438570025P CD-OWNER GUIDE VP930-3 SERIES VS10725 AUO0410 6P80 1
44 DC-00005309 2438570007P CD-OWNER GUIDE VP930 CD-DRIVER DDSKC00628T8 6P81 1
45 DC-00005307 2002370009P GUARANT CARD VP930 QSG TINSE3194T8 6P82 1
46 P-00008027 2013054031P POLYETHY BAG VP930 UG BAG SSAKD0010-1-T 6P83 1
47 N/A 2346147396P CAP,CHIP 125'C CS 0603/X7R/50V 0.047u K T C101 1
48 N/A 2346147396P CAP,CHIP 125'C CS 0603/X7R/50V 0.047u K T C102 1
49 N/A 2346147396P CAP,CHIP 125'C CS 0603/X7R/50V 0.047u K T C103 1
50 N/A 2346110296P CAP,CHIP 125'C CS 0603/X7R/50V 1000p K T C104 1
51 N/A 2346147396P CAP,CHIP 125'C CS 0603/X7R/50V 0.047u K T C105 1
52 N/A 2346147396P CAP,CHIP 125'C CS 0603/X7R/50V 0.047u K T C106 1
53 N/A 2346147396P CAP,CHIP 125'C CS 0603/X7R/50V 0.047u K T C107 1
54 E-C-0404-4423 2341122096P CAP,CHIP 125'C CS 0603/COG/50V 22p J T C108 1
55 E-C-0404-4829 2341122196P CAP,CHIP 125'C CS 0603/COG/50V 220p J T C109 1
56 E-C-0404-3815 2346410496P CAP,CHIP 85'C CS 0603/Y5V/50V 0.1u Z T C110 1
57 N/A 2346147396P CAP,CHIP 125'C CS 0603/X7R/50V 0.047u K T C111 1
58 N/A 2346147396P CAP,CHIP 125'C CS 0603/X7R/50V 0.047u K T C112 1
59 N/A 2346147396P CAP,CHIP 125'C CS 0603/X7R/50V 0.047u K T C113 1
60 N/A 2346110296P CAP,CHIP 125'C CS 0603/X7R/50V 1000p K T C114 1
61 N/A 2346147396P CAP,CHIP 125'C CS 0603/X7R/50V 0.047u K T C115 1
62 N/A 2346147396P CAP,CHIP 125'C CS 0603/X7R/50V 0.047u K T C116 1
63 N/A 2346147396P CAP,CHIP 125'C CS 0603/X7R/50V 0.047u K T C117 1
64 E-C-0404-4423 2341122096P CAP,CHIP 125'C CS 0603/COG/50V 22p J T C118 1
65 E-C-0404-4829 2341122196P CAP,CHIP 125'C CS 0603/COG/50V 220p J T C119 1
66 N/A 2336610513P CAP,MINI ELE 105'C EC 1u/ 50V 4*7 P=2.5 T C120 1
67 E-00000999 2336347613P CAP,MINI ELE 105'C EC 47u/ 16V 5*7 P=2.5 T C121 1
68 E-C-0404-3815 2346410496P CAP,CHIP 85'C CS 0603/Y5V/50V 0.1u Z T C122 1
69 E-00000999 2336347613P CAP,MINI ELE 105'C EC 47u/ 16V 5*7 P=2.5 T C123 1
70 E-C-0404-3815 2346410496P CAP,CHIP 85'C CS 0603/Y5V/50V 0.1u Z T C124 1
71 N/A 2336647513P CAP,MINI ELE 105'C EC 4.7u/ 50V 4*7 P=2.5 T C125 1
BOM LIST (VP930-3)
ViewSonic Corporation Confidential - Do Not Copy VP930-3_VP930b-3
