ViewSonic VP930b-3 - Bill of Materials and Exploded Parts Lists

Item ViewSonic P/N Ref. P/N Description Location Universal number# Q'ty
72 N/A 2336610513P CAP,MINI ELE 105'C EC 1u/ 50V 4*7 P=2.5 T C126 1
73 E-00003865 2346710596P CAP,CHIP 85'C CS 0603/Y5V/16V 1.0u Z T C127 1
74 E-C-0404-3815 2346410496P CAP,CHIP 85'C CS 0603/Y5V/50V 0.1u Z T C128 1
75 E-C-0404-3815 2346410496P CAP,CHIP 85'C CS 0603/Y5V/50V 0.1u Z T C129 1
76 E-C-0404-4423 2341122096P CAP,CHIP 125'C CS 0603/COG/50V 22p J T C130 1
77 E-C-0404-4423 2341122096P CAP,CHIP 125'C CS 0603/COG/50V 22p J T C131 1
78 E-C-0404-3815 2346410496P CAP,CHIP 85'C CS 0603/Y5V/50V 0.1u Z T C132 1
79 N/A 2336310613P CAP,MINI ELE 105'C EC 10u/ 16V 4*7 P=2.5 T C133 1
80 E-C-0404-3815 2346410496P CAP,CHIP 85'C CS 0603/Y5V/50V 0.1u Z T C134 1
81 E-C-0404-3815 2346410496P CAP,CHIP 85'C CS 0603/Y5V/50V 0.1u Z T C135 1
82 E-C-0404-3815 2346410496P CAP,CHIP 85'C CS 0603/Y5V/50V 0.1u Z T C136 1
83 E-C-0404-3815 2346410496P CAP,CHIP 85'C CS 0603/Y5V/50V 0.1u Z T C137 1
84 E-C-0404-3815 2346410496P CAP,CHIP 85'C CS 0603/Y5V/50V 0.1u Z T C138 1
85 E-C-0404-3815 2346410496P CAP,CHIP 85'C CS 0603/Y5V/50V 0.1u Z T C139 1
86 E-C-0404-3815 2346410496P CAP,CHIP 85'C CS 0603/Y5V/50V 0.1u Z T C140 1
87 N/A 2336310613P CAP,MINI ELE 105'C EC 10u/ 16V 4*7 P=2.5 T C141 1
88 E-C-0404-3815 2346410496P CAP,CHIP 85'C CS 0603/Y5V/50V 0.1u Z T C142 1
89 N/A 2336310613P CAP,MINI ELE 105'C EC 10u/ 16V 4*7 P=2.5 T C143 1
90 E-C-0404-3815 2346410496P CAP,CHIP 85'C CS 0603/Y5V/50V 0.1u Z T C144 1
91 E-C-0404-3815 2346410496P CAP,CHIP 85'C CS 0603/Y5V/50V 0.1u Z T C145 1
92 N/A 2336310613P CAP,MINI ELE 105'C EC 10u/ 16V 4*7 P=2.5 T C146 1
93 E-C-0404-3815 2346410496P CAP,CHIP 85'C CS 0603/Y5V/50V 0.1u Z T C147 1
94 N/A 2336647513P CAP,MINI ELE 105'C EC 4.7u/ 50V 4*7 P=2.5 T C148 1
95 E-C-0404-3815 2346410496P CAP,CHIP 85'C CS 0603/Y5V/50V 0.1u Z T C149 1
96 E-C-0404-3815 2346410496P CAP,CHIP 85'C CS 0603/Y5V/50V 0.1u Z T C150 1
97 E-C-0404-3815 2346410496P CAP,CHIP 85'C CS 0603/Y5V/50V 0.1u Z T C151 1
98 E-C-0404-3815 2346410496P CAP,CHIP 85'C CS 0603/Y5V/50V 0.1u Z T C152 1
99 E-00000999 2336347613P CAP,MINI ELE 105'C EC 47u/ 16V 5*7 P=2.5 T C153 1
100 E-00000999 2336347613P CAP,MINI ELE 105'C EC 47u/ 16V 5*7 P=2.5 T C154 1
101 E-C-0404-3815 2346410496P CAP,CHIP 85'C CS 0603/Y5V/50V 0.1u Z T C156 1
102 N/A 2336310613P CAP,MINI ELE 105'C EC 10u/ 16V 4*7 P=2.5 T C157 1
103 N/A 2336310713P CAP,MINI ELE 105'C EC 100u/ 16V 6.3*7 P=2.5 T C158 1
104 E-C-0404-3815 2346410496P CAP,CHIP 85'C CS 0603/Y5V/50V 0.1u Z T C159 1
105 E-C-0404-3815 2346410496P CAP,CHIP 85'C CS 0603/Y5V/50V 0.1u Z T C161 1
106 E-C-0404-3815 2346410496P CAP,CHIP 85'C CS 0603/Y5V/50V 0.1u Z T C162 1
107 E-C-0404-3815 2346410496P CAP,CHIP 85'C CS 0603/Y5V/50V 0.1u Z T C163 1
108 N/A 2346110296P CAP,CHIP 125'C CS 0603/X7R/50V 1000p K T C164 1
109 N/A 2346110296P CAP,CHIP 125'C CS 0603/X7R/50V 1000p K T C165 1
110 N/A 2346110296P CAP,CHIP 125'C CS 0603/X7R/50V 1000p K T C166 1
111 N/A 2346110296P CAP,CHIP 125'C CS 0603/X7R/50V 1000p K T C167 1
112 N/A 2346110296P CAP,CHIP 125'C CS 0603/X7R/50V 1000p K T C168 1
113 N/A 2346110296P CAP,CHIP 125'C CS 0603/X7R/50V 1000p K T C169 1
114 N/A 2346110296P CAP,CHIP 125'C CS 0603/X7R/50V 1000p K T C170 1
115 E-C-0404-3815 2346410496P CAP,CHIP 85'C CS 0603/Y5V/50V 0.1u Z T C171 1
116 E-C-0404-3815 2346410496P CAP,CHIP 85'C CS 0603/Y5V/50V 0.1u Z T C172 1
117 E-C-0404-3815 2346410496P CAP,CHIP 85'C CS 0603/Y5V/50V 0.1u Z T C173 1
118 N/A 2364600496P DIODE,SWITCH SMD MM4148 SOD-80 GRANDE D101 RA 1
119 E-D-0403-1892 2364200896P DIODE,RECT(SMD) BAS32L SOD80C PHILIPS D101 RB 1
120 E-00003534 2363600696P DIODE,SWITCH RLS4148-T11 SOD-80 ROHM D101 RC 1
121 E-00003830 2364601396P DIODE,SWITCH SMD 1N4148W-7-F SOD-123 DIODES D101 RD 1
122 N/A 2364600496P DIODE,SWITCH SMD MM4148 SOD-80 GRANDE D102 RA 1
123 E-D-0403-1892 2364200896P DIODE,RECT(SMD) BAS32L SOD80C PHILIPS D102 RB 1
124 E-00003534 2363600696P DIODE,SWITCH RLS4148-T11 SOD-80 ROHM D102 RC 1
125 E-00003830 2364601396P DIODE,SWITCH SMD 1N4148W-7-F SOD-123 DIODES D102 RD 1
126 N/A 2364600496P DIODE,SWITCH SMD MM4148 SOD-80 GRANDE D103 RA 1
127 E-D-0403-1892 2364200896P DIODE,RECT(SMD) BAS32L SOD80C PHILIPS D103 RB 1
128 E-00003534 2363600696P DIODE,SWITCH RLS4148-T11 SOD-80 ROHM D103 RC 1
129 E-00003830 2364601396P DIODE,SWITCH SMD 1N4148W-7-F SOD-123 DIODES D103 RD 1
130 N/A 2364600496P DIODE,SWITCH SMD MM4148 SOD-80 GRANDE D104 RA 1
131 E-D-0403-1892 2364200896P DIODE,RECT(SMD) BAS32L SOD80C PHILIPS D104 RB 1
132 E-00003534 2363600696P DIODE,SWITCH RLS4148-T11 SOD-80 ROHM D104 RC 1
133 E-00003830 2364601396P DIODE,SWITCH SMD 1N4148W-7-F SOD-123 DIODES D104 RD 1
134 N/A 2364600496P DIODE,SWITCH SMD MM4148 SOD-80 GRANDE D105 RA 1
135 E-D-0403-1892 2364200896P DIODE,RECT(SMD) BAS32L SOD80C PHILIPS D105 RB 1
136 E-00003534 2363600696P DIODE,SWITCH RLS4148-T11 SOD-80 ROHM D105 RC 1
137 E-00003830 2364601396P DIODE,SWITCH SMD 1N4148W-7-F SOD-123 DIODES D105 RD 1
138 N/A 2364600496P DIODE,SWITCH SMD MM4148 SOD-80 GRANDE D106 RA 1
139 E-D-0403-1892 2364200896P DIODE,RECT(SMD) BAS32L SOD80C PHILIPS D106 RB 1
140 E-00003534 2363600696P DIODE,SWITCH RLS4148-T11 SOD-80 ROHM D106 RC 1
141 E-00003830 2364601396P DIODE,SWITCH SMD 1N4148W-7-F SOD-123 DIODES D106 RD 1
142 E-D-0403-1779 2364503996P DIODE,ZENER SMD BZV55-C5V6 5% SOD-80C PHILIPS D107 RA 1
143 E-D-0403-2808 2364505616P DIODE,ZENER SMD TZMC5V6 SOD-80 5.2-6.0V VISHAY D107 RB 1
144 N/A 2364505636P DIODE,ZENER SMD BZV55-B5V6 2% SOD-80C PHILIPS D107 RC 1
145 E-D-0403-1666 2364500396P DIODE,ZENER SMD RLZ5.6B 5.45-5.73V LL-34 ROHM D107 RD 1
146 E-D-0403-1779 2364503996P DIODE,ZENER SMD BZV55-C5V6 5% SOD-80C PHILIPS D108 RA 1
147 E-D-0403-2808 2364505616P DIODE,ZENER SMD TZMC5V6 SOD-80 5.2-6.0V VISHAY D108 RB 1
