ViewSonic VS17067 - Recommended Spare Parts List

58
Recommended Spare Parts List
Item Category Part Name ViewSonic P/N Supplier P/N Ref. No. In Exploded Diagram
1
Accessories: [Adapter,
Baery, Remote Controller,
Power Cord, External
Cables, Mouse, Keyboard]
Signal Cable
CB-00012376 50.7AA18.011
2
CB-00012377 50.7AA18.041
3
CB-00012431 50.7AA18.061
4
CB-00012438 750.A0M02.0001
5
CB-00012379 750.A0M02.0011
6
Power Cord
A-00009891 027.00001.0991
7
A-00009206 27.01518.G61
8
A-00009286 27.01518.G71
9
A-00010028 027.00001.0A11
10
A-00009401 27.03218.101
11
A-00009208 27.03218.111
12
A-00009338 27.00118.001
13
A-00009205 27.00118.011
14
A-00009377 27.00818.121
15
USB Cable
CB-00011427 50.7AD05.011
16
CB-00011426 50.7M710.071
17
PC Board
Assembly: [All boards or
PCBA]
Main Board
B-00014545 7ZB.03801.0005 7
18
B-00014546 7ZB.03801.0006 7
19
Power Board
B-00014547 755.03803.0002 6
20
B-00014548 755.03803.0001 6
21
Key Pad B-00014549 755.03802.0001 2
22
USB Board B-00014550 755.03804.0001 10
23
Cabinets: [Front Bezel, All
Covers, Base/Stand
Assembly]
Side Cover C-00013618 760.03804.0001 4
24
Back Cover C-00013619 760.03805.0001 12
25
Front Bezel C-00013620 760.03803.0001 1
26
Documentaon: [Quick
Start Guide, CD Rom, Label/
Scker]
Manual Set
DC-00015303 760.03802.0001
27
DC-00015304 746.03801.0001
28
Electronic Components:
[LCD Panel, Speaker, and all
Electronic Modules]
Speaker
E-00013258 023.400F2.0001 5
29
E-00013376 023.400F2.0011 5
30
Panel
E-00013377 LM238WF2-SSK1 3
31
E-00013378 M238HCA-L3B 3
32
Hardware: [Screw, Bracket,
Hinge]
Bracket HW-00011494 760.03806.0001 9
33
Packing Material: [Carton,
Box, Foam, Bags]
Carton
P-00014712 760.03801.0011
34
P-00014677 760.03801.0001
35
Plasc Bag P-00014298 742.A2H0J.0001
36
Plascs: [Pedestal, stand/
neck, Plate, Buon, etc.]
Stand PL-00009557 760.04006.0001 13
37
Pedestal PL-00009559 760.A2H0C.0002 14
38
Stand PL-00009558 760.03808.0001 13
39
Pedestal PL-00009559 760.A2H0C.0002 14
