Installing the LCD TV
Installing the Stand
1. Lay the TV fl at on a table with the LCD screen face down. To prevent the TV from being
scratched, put a piece of soft cloth on the table on which the screen will be set. (see Figure 1)
2. Unpack the stand, one hand hold the TV and one hand pull stand with arm together. (see
Figure 2)
3. Stand the TV up. (see Figure 3)
Disconnecting the Stand
1. Lay the TV fl at on a table with the LCD screen face down. To prevent the TV from being
scratched, put a piece of soft cloth on the table on which the screen will be set. (see Figure 1)
2. Press on four corners of the hinge cover and pull as arrow direction to disengage the hinge
cover. (see Figure 2)
3. Remove the 4 screws on the hinge, then pull up the stand slowly. (see Figure 3)
4. Then connect the hinge cover to the back cover like shown below. (see Figure 4)
5. Then, you shall successfully uninstall the stand. (see Figure 5)
