3. Command Description
Length Total Byte of Message excluding “CR”
TV ID Identifi cation for each of TV
Command Type Identify command type,
“s” (0x73h) : Set Command
“g” (0x67h) : Get Command
“r” (0x72h) : Reply Command
“p” (0x70h) : RCU Pass-through
“+” (0x2Bh) : Valid command Reply
“-” (0x2Dh) : Invalid command Reply
Command Function command code: One byte ASCII code
Value[1~3] Three bytes ASCII that defi nes the value
CR 0x0D
4. Set-Function Listing
The PC can control the LCD Monitor for specifi c actions. The Set-Function command allows
you to control the LCD monitor behavior in a remote sit through the RS232 port. The Set-
Function packet format consists of 11 bytes.
Set-Function description:
Length Total Byte of Message excluding “CR”
TV ID Identifi cation for each of TV. The TV ID doesn’t be supported by HDTV “power
on” command.
If we want to set all TV settings, TV ID can use “99” to achieve, and it will not
have Reply command on this function.
Command Type Identify command type,
“s” (0x73h) : Set Command
Command Function command code: One byte ASCII code
Value[1~3] Three bytes ASCII that defi nes the value
CR 0x0D
Set-Function format:
Send (Command Type= “s”)
Name Length ID Command
Type
Command Value1 Value2 Value3 CR
Byte Count 1 Byte 2 Byte 1 Byte 1 Byte 1 Byte 1 Byte 1 Byte 1 Byte
Bytes order 1 2~3 4 5 6 7 8 9
(Command Type= “s”, Only for HDTV power on)
Name Length Command
Type
Command Value1 Value2 Value3 CR
Byte Count 1 Byte 1 Byte 1 Byte 1 Byte 1 Byte 1 Byte 1 Byte
Bytes order 1 2 3 4 5 6 7
