ViewSonic VTMS2431
Getting Started
Installing the LCD TV
Installing the Stand
1. Lay the TV at on a table with the LCD screen face down. To prevent the TV from being
scratched, put a piece of soft cloth on the table on which the screen will be set. (see Figure 1)
2. Unpack the stand, one hand hold the TV and one hand pull stand with arm together. (see
Figure 2)
3. Stand the TV up. (see Figure 3)
Disconnecting the Stand
1. Lay the TV at on a table with the LCD screen face down. To prevent the TV from being
scratched, put a piece of soft cloth on the table on which the screen will be set. (see Figure 1)
2. Press on four corners of the hinge cover and pull as arrow direction to disengage the hinge
cover. (see Figure 2)
3. Remove the 4 screws on the hinge, then pull up the stand slowly. (see Figure 3)
4. Then, you shall successfully uninstall the stand. (see Figure 4)

ViewSonic VTMS2431 Specifications

General

Display diagonal	24 \
Display brightness	300 cd/m²
Display technology	LCD
Native aspect ratio	16:9
Viewable size diagonal	599 mm
Viewing angle, vertical	170 °
Contrast ratio (dynamic)	10000:1
Contrast ratio (typical)	1000:1
Viewing angle, horizontal	160 °
Power requirements	100 - 240 V
Digital vertical frequency	60 - 75 Hz
Digital horizontal frequency	30 - 64 kHz
Operating relative humidity (H-H)	10 - 65 %
Operating temperature (T-T)	0 - 40 °C
Certification	FCC UL RoHS NOM BETS-7 CB
Analog signal format system	NTSC
RS-232 ports	1
Product color	Black
LED indicators	Stand-by
Panel mounting interface	100 x 100 mm
Power consumption (typical)	60 W
RMS rated power	10 W
Number of speakers	2

Weight and Dimensions

Depth (with stand)	211 mm
Width (with stand)	567 mm
Height (with stand)	442 mm
Weight (with stand)	7400 g
Depth (without stand)	85 mm
Height (without stand)	387 mm
Weight (without stand)	6400 g
