ViewZ vz19rtld - Monitor Controls and Functions; Front Key Control Panel

C. FRONT KEY CONTROL
1. SOURCE /
Select input source, and move the previous menu.
2. MENU
Activates and exits the On Screen Display.
This button can also be used to move previous menu or status.
3, 4. AUTO/▲, ▼
These buttons allow user to move the sub-menu of the activated function.
AUTO/▲ : Auto geometry adjustment.
▼ : Audio mute on or off when disappeared OSD.
5/6. ◀ VOL ▶
Adjust the volume and menu settings.
7. IR Sensor
Remote controller sensor. The remote controller is optional.
8. POWER ON/OFF( / I )
Turn the power ON or OFF. There will be a few seconds delay before the display appears.
The power LED lights with green when the power is turned ON.
The power is turned off by pressing the power switch again and the power LED goes to Red
8 ……………………………………………………………………. INSTRUCTION MANUAL
1
2
3
4
5
6
7
8
