32
Gasifying boiler Vigas
20. ELECTRIC SCHEME
ELECTRIC SCHEME
VIGAS
VIGAS
LC
16,25,40
29UD kW
60,80,100 kW
16,25,40 kW
60,80,100 kW
No
Description Code
1
AK 4000D Display
4001




2
AK 4001S Power board
4002
 
– –
2a
AK 4000SL Lambda board
4003 – –
 
3 Fan
0514

2

2
0516 –

–

3a
Condenser
0515

2

2
4
STB fuse
3029




5 Thermometer type KTY 3026
   
6 Gas sensortype PT 1000 3027
   
7 Servo Belimo 3008 – –
 
8 Lambda sensor 3009 – –
 
9
Supply RS 25 - 12
4004
–
–


10
Accumulator thermometer
type KTY (4m)
3032




11
Discharge fan
0507

–

–
0508




12
Expander AK4000
SET




13
Memory modul AK4000M
4007




14
Indoor thermostat 3030




K1
Connector 3025
   
K2
Fan wire
3010

–

–
3011 –

–

K3
Wire set for STB fuse
3015




K4
Thermometer connection modul
3022

–

–
3023 –

–

K5
Main ground wire 3018
   
K5a
Ground wire for the control cover panel 3019
   
K6
Communication wire AK40000(4P4C 0,4m)
4006
   
K7
Lambda sensor connection modul
3024
–
–

–
3024
–
–
–

K8
Wire for servo-unit 3013 – –
 
K9
Wire set for power supply RS 25 - 12 4005 – –
 

standard,

extra cost, – not available,

only for 40, 40LC,

only for 100, 100LC (2psc)
