LAN Subsystem
The ethernet controllers support the following features:
• 10/100/1000 BASE-T IEEE 802.3 compliant
RJ-45 LAN Connector LEDs
The two LEDs are built into the RJ-45 LAN connector located on the back panel. These
LEDs indicate the status of the LAN as shown in Table 1.
Item
Description
A
Link/Activity LED (Green)
B
Link Speed LED (Orange/Yellow)
Figure 2: LAN Connector LED Locations
Table 1: LAN LED Status
LED
LED Colour
LED State
Description
Link
Green
Off
LAN activity is occurring.
On
LAN link is established.
Blinking
LAN activity is occurring.
Data
rate
Green/yellow
10 Mb/s data rate is selected.
100 Mb/s data rate is selected.
1000 Mb/s data rate is selected.
