2
BASIC SPECIFICATIONS AND DIMENSIONS - PROFESSIONAL MODELS
DDEESSCCRRIIPPTTIIOONN VVCCBBBB336633
Overall Width 36” (91.5 cm)
Overall Height from Bottom Min. 82 3/4” (210.2 cm) to Max. 84 1/16” (213.5 cm)
Overall Depth from Rear To front edge of side trim 22 3/16” (56.4 cm)
To front of top grille 24 11/16” (62.7 cm)
To end of handle bracket 27 1/4” (69.2 cm)
Cutout Width 35 1/2” (90.2 cm)
Cutout Height 82 7/8” (210.5 cm) min.; 84 1/16” (213.5 cm) max.
Cutout Depth 24” (61.0 cm) min.
Electrical Requirements 115 volt, 60 Hz, 15 amp dedicated circuit; 3-wire cord with
grounded 3-prong plug attached to product.
Maximum Amp Usage 9.9 amps
Inlet Water 1/4” copper tubing inlet waterline;
Requirements minimum 20 psi; maximum 120 psi
Overall Interior Dimensions
•Refrigerator 15.2 cu. ft. (.43 cu. meters)
•Freezer 5.1 cu. ft. (.14 cu. meters)
•Total Capacity 20.3 cu. ft. (.57 cu. meters)
Approximate Shipping Weight 500 lbs. (227.3 kg)
BASIC SPECIFICATIONS AND DIMENSIONS - DESIGNER MODELS
DDEESSCCRRIIPPTTIIOONN DDDDBBBB336633
Overall Width 36” (91.5 cm)
Overall Height from Bottom Min. 82 3/4” (210.2 cm) to Max. 84 1/16” (213.5 cm)
Overall Depth from Rear To rear edge of side trim 23 13/16” (60.5 cm)
To front of top grille 24” (61.0 cm)
To end of handle bracket 26” (66.0 cm)
Cutout Width 36” (91.5 cm)
Cutout Height 82 7/8” (210.5 cm) min.; 84 1/16” (213.5 cm) max.
Cutout Depth 24” (61.0 cm) min.
Electrical Requirements 115 volt, 60 Hz, 15 amp dedicated circuit; 3-wire cord with
grounded 3-prong plug attached to product.
Maximum Amp Usage 9.9 amps
Inlet Water 1/4” copper tubing inlet waterline;
Requirements minimum 20 psi; maximum 120 psi
Overall Interior Dimensions
•Refrigerator 15.2 cu. ft. (.43 cu. meters)
•Freezer 5.1 cu. ft. (.14 cu. meters)
•Total Capacity 20.3 cu. ft. (.57 cu. meters
Approximate Shipping Weight 500 lbs. (227.3 kg)
