3
BASIC SPECIFICATIONS AND DIMENSIONS - FULL OVERLAY MODELS
DDEESSCCRRIIPPTTIIOONN DDFFBBBB336633
Overall Width 36” (91.5 cm)
Overall Height from Bottom Min. 82 3/4” (210.2 cm) to Max. 84 1/16” (213.5 cm)
Overall Depth from Rear To rear edge of side trim 23 13/16” (60.5 cm)
To front of top grille 24 3/4” (62.9 cm)
To front edge of door trim 24” (61.0 cm)
Cutout Width 36” (91.5 cm)
Cutout Height 82 7/8” (210.5 cm) min.; 84 1/16” (213.5 cm) max.
Cutout Depth 24” (61.0 cm) min.*
Electrical Requirements 115 volt, 60 Hz, 15 amp dedicated circuit; 3-wire cord with
grounded 3-prong plug attached to product.
Maximum Amp Usage 9.9 amps
Inlet Water 1/4” copper tubing inlet waterline;
Requirements minimum 20 psi; maximum 120 psi
Overall Interior Dimensions
•Refrigerator 15.2 cu. ft. (.43 cu. meters)
•Freezer 5.1 cu. ft. (.14 cu. meters)
•Total Capacity 20.3 cu. ft. (.57 cu. meters
Approximate Shipping Weight 500 lbs. (227.3 kg)
**FFuullll oovveerrllaayy mmooddeellss ffiitt fflluusshh iinn 2255”” ((6633..55 ccmm)) ddeeeepp ccaabbiinneett ooppeenniinnggss.. TThheeyy ccaann bbee iinnssttaalllleedd iinn ssttaannddaarrdd 2244”” ((6611..00 ccmm))
ddeeeepp ooppeenniinnggss.. TThhee ddoooorr ffaacceess aanndd ttoopp ggrriillllee wwiillll pprroottrruuddee 33//44”” ((11..99 ccmm)) iinnttoo t
thhee rroooomm..
