Viking C-1000B - Installation Guide; Connecting Doorboxes and Cameras

EARTH
GND
C.O. LINE
INPUT
OUT TO
PHONES
KEYLESS
C.C. INPUT
DOOR
BOX 1
DOORBOX
13VAC PWR
DOOR
BOX 2
N.O. COM N.C.
DOOR STRIKE 1
SIG GND
VIDEO 1 IN
SIG GND
VIDEO 2 IN
SIG GND
VIDEO OUT
N.O. COM N.C.
DOOR STRIKE 2
TALK BATTERY
OFF ON
C
LED1
C
LED2
C
LED3
ON
1 2 3
COM N.O. N.C. - - - - AUX.
CONTACT
OUTPUT
or
Standard
Analog Phones
Unused Trunk Input
of PABX/KSU (set
"Talk Battery"
switch to ON)
Talk Battery Switch
OFF ON
C.O. Line
Earth Ground
(above) Doorbox 2:
Back view of the W-2000A
shown, not included (DOD 170)
**CCTV Camera 1
(not included)
**CCTV Camera 2
(not included)
**TV, Video Monitor, Video Recorder
or RF Modulator (not included)
* Power
* Power
ON
1 2 3
DIP Switches
ON
OFF
VIKING
©
VIKING
ELECTRONICS
HUDSON,
WI
54016
DOOR ENTRY / CCTV VIDEO
CONTROLLER
POWER 13.8V AC
MODEL C-1000B
PHONE LINE
INPUT
EARTH
GND
21 3 4 5 14 15 16
LINE OUT
TO PHONES
67
KEYLESS CONTACT
CLOSURE INPUT
DOORBOX 1
DOORBOX 2
891011
DOORBOX
PWR OUTPUT
12 13
DOOR STRIKE 1
N.O.
COM
N.C.
17 18 19
DOOR STRIKE 2
N.O.
COM
N.C.
Ground
Signal
Ground
Signal
Signal
Ground
ON
1 2 3
ON
1 2
ON
1 2 3
ON
1 2
5A @ 30V DC
250V AC
maximum
(not included)
Doorstrike /
Magnetic Lock 2
Door
5A @ 30V DC
250V AC
maximum
(not included)
Doorstrike /
Magnetic Lock 1
Door
(left) Doorbox 1:
Back view of the W-1000
shown, not included (DOD 170)
Note: Over 100ft power
runs require separate
doorbox power adapters.
* Note: Use the power supply
recommended and/or supplied
by the camera manufacturer.
Installation
IMPORTANT: Electronic devices are susceptible to lightning and power station electrical surges from both the AC
outlet and the telephone line. It is recommended that a surge protector be installed to protect against such surges.
3
A. One or Two Doorboxes Sharing a Phone Line and Controlling Two Optional Cameras
See Operation, section A.
** Note: The C-1000B must be programmed with (
Q 8) to control cameras. In the CCTV video control mode ( Q 8),
Auxiliary Contact Mode is disabled.
