VIKING TECHNICAL SUPPORT 1.800.908.0884
23
Wireless Communication Options
!
Technical Tip: DO NOT set the “Timer” and/or “Overlap” features on both operators
Control Boards. Only turn these features on at the Master Control Board.
MASTER/SLAVE SETUP
REQUIRED ADD-ON: Choose option A or B
A.
Viking Konnect - Wireless Master/Slave Kit
PART# VA-KONNECT-MS
B.
Viking Blue - Wireless Master/Slave Kit
PART# VA-BLUE-MSKT
Green LEDs will be illuminated
solid when communication is ON.
Connect the Modules provided to the “V.K” plug & play connection of each operators
Control Board. It is not important which board the master or slave module is placed on.
