System Requirements
• IBM compatible personal computer with:
Windows XP or newer operating system.
Adobe Acrobat Reader 8 or higher.
120MB minimum free hard drive space for installation.
64MB of free physical RAM.
• CTG-2A hardware
• Ethernet switch with available port
• Ethernet cable (NOT provided with CTG-2A hardware)
• Internet connection
PC Programming
ATTENTION: Before using the CTG-2A, the CTG-2A
application must be installed.
A DVD is included with each CTG-2A. The DVD contains the
CTG-2A application used to program the unit using a PC running
Windows XP or newer OS (see System Requirements above).
Install the application on your PC by placing the DVD into your
PC’s drive. Click “I Accept” on the bottom of the first screen, then
select “CTG-2A” and click the “Install” button. Follow the directions
on the screen.
To start the CTG-2A application, click on the CTG-2A Programmer
icon on your desktop. When you first start the program the
Connect screen will appear. The software will scan the local
network for the CTG-2A automatically when this screen is started.
Select a device from the list or enter its address in the field and
click “Connect”. If you want to work offline, click “Work Offline”
When you exit this screen, the Event Programming screen will
appear.
The Event Programming
screen allows the user to
enter/program individual events
to activate at specific times
during the day, week or on
specific dates. Events include:
Play specific Wave file, Enable
or Disable the system, Activate
Time Sync, Turn Aux Relay
On/Off, Activate programmable
timed Aux Relay and Change
Schedule on specific dates.
The Event Programming
example shown on page 11 is
included on the DVD and
factory loaded into the CTG-2A
allowing you to get familiar with
programming or modify this file
for your own use.
