Viking DEDO - Utility Requirements; Gas; Electrical; Plumbing

COOKING
Designer Select & Premiere Built-In Electric
27”/30”W. Single/Double Oven
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
RELEASED 12/1/07
©2007 VRC—INFORMATION SUBJECT TO CHANGE
28–1/8”
(
71.4 cm)
17”
(43.2 cm)
A
24”
(61.0 cm)
5”
(12.7 cm) min.
4”
(
10.2 cm)
Ju
nctio
n
Box
Lo
cation
Make sure walls
are perpen
dicular
A
24”
(61.0 cm
)
28–1/8”
(71.4 cm)
5”
(12.7 cm) min.
4”
(10.2 cm
)
Ju
nction
Box
Lo
c
ation
Make su
re
walls are
per
pendicular
4–3/4”
(12.1 cm)
DESO127/527 DEDO127/527 DESO130/530 DEDO130/530
Cutout width (A) 25-1/2” (64.8 cm) 25-1/2” (64.8 cm) 28-1/2” (72.4 cm) 28-1/2” (72.4 cm)
Cutout height (from bottom) 28-1/8” (71.4 cm) 50-5/8” (128.6 cm) 28-1/8” (71.4 cm) 50-5/8” (128.6 cm)
Cutout depth 24" (61.0 cm)
UTILITY
REQUIREMENTS
GAS
• Not applicable
ELECTRICAL
• Five-foot flexible steel
conduit included.
Equipped with
No.10 ground
wire in unit. Fuse
separately.
o Four-wire with
ground
o 240 – 208/120
V/60 Hz
o 30 amp electrical
connection for
singles
o 50-amp electrical
connection for
doubles
• Max. amp usage—
(240V/208V)
o Single—24.0/20.8
o Double—40.0/34.7
PLUMBING
Not applicable
Installation Requirements
ACCESS REQUIREMENTS
50–5
/8
”
(128.6 cm)
15–1/4”
(38.7 cm)
min. to floor
A
24”
(61.0 cm)
5”
(12
.7 cm) m
4”
(10.2 cm)
Junction
Box
Lo
c
ati
on
Make sure walls
are perpendicular
Built-in
Double Oven
Undercounter
Single Oven
Built-in
Single Oven
DESO127/130
Designer Select
Single Oven
DEDO127/130
Designer Select
Double Oven
DESO527/530
Designer Premiere
Single Oven
DEDO527/530
Designer Premiere
Double Oven
