Viking Designer Series Installation Guide

4
HHEEIIGGHHTT OOFF HHOOOODD
The bottom of the hood should be 30” (76.2 cm) min. to 36” (91.4 cm) max. above the countertop. This would
typically result in the bottom of the hood being 66” (167.6 cm) to 72” (182.9 cm) above the floor. For best
performance, it is recommended that the bottom of the hood be 30” (76.2 cm) to 33” (83.8 cm) above the
countertop. These dimensions provide for safe and efficient operation of the hood.
CClleeaarraannccee DDiimmeennssiioonnss
18”
(45.7 cm)
30”
(76.2 cm) Min.
36”
(91.4 cm) Max.
36”
(91.4 cm)
CCoouunntteerrttoopp

Viking Designer Series Specifications

General

Type	Built-In
Capacity	14 place settings
Energy Star Certified	Yes
Tub Material	Stainless Steel
Stainless Steel Interior	Yes
Adjustable Upper Rack	Yes
Water Consumption	3.5 gallons
Dimensions	34-1/2" H x 23-7/8" W x 24" D
