5
The speed dial number programmed in location #00 is the telephone or extension number that is
dialed when the “Call” button is first pressed. Additional speed dial numbers will be dialed when
there is no answer or a busy signal is detected and the next number redial features are activated.
The E-35 will cycle through the programmed speed dial numbers until answered. To program,
enter the desired speed dial number followed by the memory location number (#00 - #04).
To clear a speed dial location, simply enter the memory location (#00 - #04) alone. The E-35 is
factory set with no speed dial number programmed.
Programming
B. Security Code (memory location #19)
The security code allows the user/installer to program the E-35 phone while DIP switch 3 is in the ON (normal) position.
The factory set security code is 845464 (V-I-K-I-N-G). It is recommended that the factory set security code be changed.
Example: To store 123456 as the security code:
Enter Your Security Code Here:
#19
Note: The security code must be 6 digits and cannot include a
Q
or a #.
The E-35 phone can be programmed from any Touch Tone phone using a C.O. line, analog PABX/KSU station, or a DLE-200B Line
Simulator. For more information on the DLE-200B, see DOD# 605.
2. Without the Security Code
1. Using the Security Code
Step 1. Move DIP switch 2 to the ON position (sets unit to answer incoming calls, see section H).
Step 2. From a Touch Tone phone call the line attached to the E-35 phone.
Step 3.
When the E-35 phone answers, enter the 6-digit security code (factory set to 845464, see section B). A double beep should then
be heard indicating you have entered the programming mode.
Step 1. Move DIP switch 2 to the ON position (sets unit to answer incoming calls, see section H).
Step 2. Move DIP switch 3 to the OFF position (incoming calls enter Programming without security code, see section H).
Step 3. From a Touch Tone phone call the line attached to the E-35.
Step 4. When the E-35 answers, a double beep will be heard and will automatically enter the programming mode.
Step 5. When finished programming, move DIP switch 3 back to the ON position (see section H).
Step 1. Access programming as shown in Programming section A above.
Step 2. Enter 123456 #19.
Step 3. Hang-up.
Warning: Failure to do step 5 above will cause the E-35 phone to call Viking Technical Support instead of your programmed number.
Note: If a valid memory position is entered, a double beep will be heard. Four beeps indicate an error.
C. Quick Programming Features
D. Speed Dial Numbers (Memory Locations #00 - #04)
Note: Up to 20 digits can be stored in each dial position. Special features such as pause, mode change, touch tone
Q
and # count as single digits.
Description Enter Digits + Memory Location
First speed dial number 0-20 digits then #00
Secondspeed dial number 0-20 digits then #01
Third speed dial number 0-20 digits then #02
Fourth speed dial number 0-20 digits then #03
Fifth speed dial number 0-20 digits then #04
To add a Q at any point in the dialing string
QQ
To add a # at any point in the dialing string
Q#
To add a four second pause at any point in the dialing string
Q7
Miscellaneous options (factory set to 001210) 6 digits then #17
Timing/Dialing options (factory set to 234721) 6 digits then #18
Security code (factory set to 845464) 6 digits then #19
Exit programming and disconnect #7
Reset all programming to factory default settings ###
To Program: Enter:
QQQ
#
Q#
4 second pause
Q7
0, 1, 2 .... 9 0, 1, 2 .... 9
A. Accessing the Programming Mode
