VIKING TECHNICAL SUPPORT 1.800.908.0884
23
Wireless Communication (Bluetooth) Option
!
Technical Tip: DO NOT set the “Timer” and/or “Overlap” features on both operators
Control Boards. Only turn these features on at the Master Control Board.
MASTER/SLAVE SETUP
REQUIRED ADD-ON:
1.
Viking Blue - Wireless Master/Slave Kit
PART# VA-BLUE-MSKT
Connect one Bluetooth Module, provided with VA-BLUE-MSKT, to the “V-Blue” plug &
play connection of each operators Control Board.
Green LEDs will be illuminated
solid when communication is ON.
To Next Page
