VIKING TECHNICAL SUPPORT 1.800.908.0884
38
TROUBLESHOOTING
LCD Display References
LCD MSG Meaning
Page 39
TS Ref #s
ERR BAT
LOW
The battery is low
1, 2, 3,
4
ERR EPS2
WRONG
The EPS (Electronic Position Sensor) has one of the following conditions:
a) The EPS is not properly adjusted b) The EPS has a potential connection
problem c) The EPS has the wrong cable harness
X
ERR EPS2
MISSING
Missing EPS2 cable harness
14, X
ERR FUSE
15 AMP
15 AMP motor fuse is blown
7, 11, 12
ERR FUSE
20 AMP
20 AMP motor fuse is blown (Only H-10)
7, 11, 12
ERR FUSE
30 AMP
30 AMP motor fuse is blown (Only Q-7)
7, 11, 12
ERR EMI
NO EMI
No EMI board detected
15
ERR EMI
NO FUSE
4 Amp main fuse is blown on Modular Power Box
2
ERR EMI
NO AC
There is no AC line detected from the EMI Board in the Modular Power Box
1, 4
ERR EMI
PROTECT
Lightning strike protection for the EMI Board in the Modular Power Box
needs to be replaced
X
ERR SENS
CURRENT
Motor Current Sensor need replacement
X
ERR SENS
MOTOR
Motor is not detected
7, 8
