Technical Information – Refrigerator
To avoid electrical shock which can cause severe personal injury or death, disconnect
power to refrigerator using power switch before servicing. Wires removed during
disassembly must be replaced on proper terminals to insure correct earth ground and
polarization. After servicing, reconnect power using power switch.
Refrigerator Center Freezer
Compartment Food Compartment
Percent Run Cycle/24 hr Average temperature Food Average
Kw/24 hr ± 0.4 Time ± 10% ± 25% ± 3°F Temperature ± 3°F
Ambient° F 65° 90° 110° 65° 90° 110° 65° 90° 110° 65° 90° 110° 65° 90° 110°
1.2 2.3 4.2 28 52 100 30 32 0 39 39 45 3 3 3
Temperature Relationship Test Chart
T-3 Suction Average Total Suction Pressure Head Pressure
T-1 Outlet ± 3° F T-1 Inlet ± 3° F Line Wattage ±10% ± 2 PSIG ± 5 PSIG
± 7°F
Ambient °F 65° 110° 65° 110° 65° 110° 65° 110° 65° 110° 65° 110°
-14 -14 -14 -14 25 103 157 168 0 0 110 157
