Viking Vcbb536rss - Kickplate Installation; Door Stop Adjustment

43
3
1
2
20
1
2
21
110˚
120˚
90˚
Open refrigerator door so door stop and shoulder
screw are accessible.
NOTE: Shoulder screw should be in 110˚ door opening
position.
Remove shoulder screw and place in 90° or
120° position.
3
1
2
22
1
2
23
110˚110˚110˚
90˚
120˚120˚120˚
Open refrigerator door so door stop and
shoulder screw are accessible.
NOTE: Shoulder screw should be in 110˚ door opening position.
Remove shoulder screw and place in
90˚ or 120˚ position.
42
Turn on water supply and check for leaks.
Lift unit off rollers to desired height and level unit using
a 5/16” head wrench.
NOTE: DO NOT use an electric device. Overtightening
can cause damage.
Attach positive secure self-tapping bolts to 2x4
using a 22” extension.
Verify that drain pan is installed and aligned.
Align holes on both ends of louvered panels and insert
screws.
Using a Phillips screwdriver, attach the
kickplate to the unit and adjust to desired height.
14
15
Wall
2 x 4
Refrigerator
Screw
16
17
1
2
18
2
1
3
19
Kickplate Installation
Door Stop Adjustment
(Side-by-Side)
Door Stop Adjustment (Bottom-Mount)
