Viking VGR7482 - Dimensions - Ranges

7
35-7/8”
(91.1 cm)
35-15/16”
(91.3 cm) min.
to
37-9/16”
(95.4 cm) max.
47-7/8”
(121.6 cm)
Note: Unit shown with standard island trim.
Note: All ranges installed with a backguard against a combustible wall require a standoff with the
backguard which will add 3/4” (1.9 cm) to the overall range depth.
35-15/16”
(91.3 cm) min.
to
37-9/16”
(95.4 cm) max.
19-3/8”
(49.2 cm)
46-5/16”
(117.6 cm)
26-15/16”
(68.4 cm)
25-1/4”
(64.1 cm)
8”
(20.3 cm)
27-3/4 (70.5 cm)
2-1/4”
(5.7 cm)
30” (76.2 cm)
Dimensions - 36”/48” Ranges
