Disassembly
22 SMR-0003 © Viking Range Corporation
Replacing the Top LED Light:
Loosen the screws to the control housing. You do 1.
not need to remove them.
Pull the control housing forward out of the screw 2.
slots.
Look inside the control housing and remove the wire 3.
connector to the light.
Press down and out on the LED bulb and lens. You 4.
will need to press the release tab on the lens.
Remove old bulb and set aside.5.
Insert new bulb and reverse steps 1-4 to complete.6.
Replacing the Divider LED Light:
Remove screws to the divider section and pull the 1.
divider out from the unit.
Flip the divider over for easier access to the lens 2.
assembly. Be careful not to disturb other wiring
inside the unit.
Press in on the lens release tabs while 3.
simultaneously prying the lens upward using a at-
blade screwdriver. The release tabs are located at
the midpoint of the front and rear edge of the lens.
Unhook lens from wire connector and remove it from 4.
the divider. Discard the lens.
Attach wire connector to new lens and snap lens 5.
back into place.
Reattach divider section to the unit.6.
To avoid risk of electrical shock, personal injury, or death, disconnect electrical power source to unit, unless test
procedures require power to be connected. Discharge capacitor through a resistor before attempting to service.
Ensure all ground wires are connected before certifying unit as repaired and/or operational.
