8
SL24.D
EN
PAR
P07
Output 14 type of open gate warning loght
(SCA)
(1)
Gate closed: not active
Gate not closed: active xed
1
Gate closed: not active
Gate in opening: slow ash
Gate not closed: active xed
Closing gate: quick ash
2
Gate stopped: active xed
Gate in opening: slow ash
Closing gate: quick ash
3
P08
Safety input test (OFF)
Test not active OFF
Test active on input 62 1
Test active on input 63 2
Test active on both inputs 62 and 63 3
P09
Slowdown distance during closing
Gate travel in cm at slow down speed during
closing
(75)
No slow down 0
Maximum closing slow down travel 311
P10
Slowdown distance during opening
Gate travel in cm at slow down speed during
opening
(50)
No slow down 0
Maximum opening slow down travel 311
P11
Normal opening speed (100)
Minimum speed 50
Maximum speed 100
P12
Normal closing speed (100)
Minimum speed 50
Maximum speed 100
P13
Opening slow down speed (30)
Minimum slow down speed 10
Maximum slow down speed 75
P14
Closing slow down speed (30)
Minimum slow down speed 10
Maximum slow down speed 75
P15
Motor force (%).
Sets the value of the force given to the motor
to move the gate
(3)
Minimum force 1
Maximum force 20
P16
Intensity of the stop during opening (1)
Sudden stop 0
Soft stop 5
P17
Intensity of the stop during closing (1)
Sudden stop 0
Soft stop 5
P18
Function of inputs n. 51 and 52 and radio
commands
(0)
51: step-by-step or collective command
52: pedestrian command
0
51: open only command
52: close only command
1
51 & radio command on channel 1: open only
command
52 & radio command on channel 2: close
only command
2
PAR
P19
Safety input n. 62 (1)
Photocell on closing (PHC)
- with the gate stopped, allows the gate to open
- during the opening does not intervene
- with the gate open, does not allow it to close
and when released will reload the pause time
- on closing, reopens the gate immediately
1
Photocell (PH):
- with the gate stopped, does not allow the
gate to open
- during opening stops the movement and
when released proceeds with opening
- with the gate open, does not allow it to close
and when released will reload the pause time
- on closing stops the movement and when
released reopens the gate
2
P20
2nd radio channel function (PED)
The remote control button associated with
the 2nd radio channel activates output 12 as
an auxiliary radio output (RAU) for the time
set in parameter P21
12
The remote control button associated with
the 2nd radio channel activates the pedes-
trian opening. The output 12 functions as a
courtesy light (LCO): it is activated when the
gate moves and remains active for 100 s
after the gate stops
PED
P21
Output 12 as auxiliary radio output timer
(RAU)
(1)
1 s (shortest time) 1
60 s (longest time) 60
P22
Pedestrian opening position (cm) (150)
Shortest pedestrian opening position 0
Longest pedestrian opening position 311
P24
Acceleration
Acceleration ramp until normal speed is
reached
(1)
Maximum acceleration 1
Minimum acceleration 5
P25
Deceleration ramp
Deceleration ramp between normal and slow
down motor speed
(8)
Soft ramp (minimum acceleration) 1
Steep ramp (maximum acceleration) 8
P27
Flashing light during battery operation (OFF)
Flashing light not active in battery operation OFF
Flashing light active during battery operation ON
P28
Battery operation mode (0)
Normal operation 0
After an opening command the gate remains
open
1
After the power goes o, the gate opens and
stays open
2
P29
Dead-man operation (0)
Dead-man not active 0
Emergency dead-man:
- In regular operating conditions, standard
operation
- If safaties are engaged, dead-man opera-
tion only on input 51 as a cycle command
(open-close-open) no matter the setting for
parameters P03 and P18. Remote controls
are disabled
1
Dead-man active:
- step-by-step command disabled, remote
controls disabled. The board accepts open
and close mantained commands only
2
