Vimar ELVOX K40517.R User Manual

EN
18
Roxie: 40170
4.2 Access control
The outdoor station is equipped with an access control reader for keys or transponder cards.
The reader operates in the area indicated in the image below.
Transponder card/key reading
area
The keys/cards always activate the same actuation congured in the Due Fili Plus system. This may be the lock, relay or
extensions envisaged by the system.
The keys or transponder cards are congured using the View Wireless app (with Administrator prole).
For more information refer to the "View Wireless" manual available at www.vimar.com.
4.2.1 Access control signals
Green RedGreen
LED Meaning
-
Green LED
• 3 ashes → access/remote actuation from card + “beep” and possibly voice message
Red LED
• 3 ashes → invalid card reading + “boop”
