Vimar ELVOX TAB 7548 User Manual

b. Enabled
2. Polarity state active
a. Contact normally open (default)
b. Contact normally closed
3. Activation delay
a. 0.1 s (default)
b. 0.5 s
c. 1 s
d. 2 s
4. Signalling mode
a. None
b. LED associated to the Stair Light button (default)
c. Sound
According to the selected signalling type, apart from the rst, the timer
is as follows:
STATE LED timer Sound timer
The internal unit waits to
receive the alert from the
switchboard
Flashing with a
cycle of 0.5 s on /
0.5 s off
A 2 KHz tone for
0.2 s
The internal unit has re
-
ceived conrmation of the
receipt of the message from
the switchboard
Flashing with a
cycle of 0.1 s on /
0.1 s off
A 1 KHz tone for
0.1 s
Conguring with SAVEPROG Software
SaveProg is PC software designed for advanced configuration of Due
Fili Plus Systems.
Updating
The device is updated via USB connection.
Follow the WinBoot operating instructions.
To update the device:
1. disconnect it from the Due Fili bus
2. connect it to the PC via USB
3. start the WinBoot update within 30 seconds.
Before answering the LED associated to the
button stops ashing, if
it was ashing previously to indicate missed calls.
Answering the current call from the switchboard also causes the ashing
to stop once the indoor station returns to stand-by (only on the indoor
station the call was answered from). The same result can be obtained
by also reactivating the ringtone, by making an intercom call, or by an-
swering a call.
N.B.: the missed call signal remains also in the case of a power outage.
Lock command
In standby mode (handset hung up) or during a conversation, pressing
the button sends the unlocking command (by default the last call-
ing entrance panel).
Self-start with dedicated button (button )
To self-start to the master panel, briey press the button. To stop
the communication, lift the handset. Replace the handset to end the
conversation.
Calling the concierge switchboard
To make a call to the concierge switchboard (if installed in the system),
raise the handset and send the call by pressing the button.
Alert
Internal Unit 7548, together with porter switchboard Art. 40510, creates
a system that can send an alert to the switchboard operator even when
the Due Fili bus is busy. In contrast to other internal units, it is possible
to use only the pair of terminals FP-M as an input, not the buttons. In this
case the local landing call function is lost. The FP-M operating mode is
selected using SaveProg.
1. Activate input FP-M. See below for the description of the two activa
-
tion possibilities.
2. The internal unit waits to receive the alert from the switchboard. In
the meantime, the chosen signalling is sent to the user according to
the table below. On receipt of the message, the switchboard emits a
double beep and displays a red envelope icon to alert the operator.
3. If it does not receive a replay, the internal unit resends the message
every 10 s. After 5 attempts with no reply the internal unit stops send
-
ing the messages.
4. When an internal unit receives conrmation of the receipt of the mes
-
sage by the switchboard, the chosen signalling is sent to the user
according to the table below. Normally the time between the sending
of the request and conrmation of reception is less than a second.
5. Until the switchboard calls the internal unit to service the request, the
internal unit resends the message every 120 s. At each message,
the switchboard emits two meets and increases count of messages
received. The counter can be viewed by opening the list of alerts in
the switchboard. The sending of messages never terminates. It con
-
tinues until the end of the service described in the next point, unless
the switchboard is powered off or removed from the system, in which
case the internal unit, after 5 unsuccessful attempts starting from the
rst timeout of 120 s, will return to standby mode and the LED on the
LOCK key will stop ashing.
6. If the switchboard operator calls the internal unit from the list of warn
-
ings, and only from this, a message is sent to the internal unit via the
Due Fili bus to end the Alert procedure so the relative signal is no
longer sent to the user.
Note: if the internal unit is switched off, when it is switched back on again
the function starts again from the beginning.
Alert Conguration
Use SaveProg to select some of the characteristics of the Alert function:
1. Enabling
a. Disabled (default)
21
TAB: 7548
EN
