Vintec V30SGME - Dimensional Drawings

V30SGME V30SGMEBK V30SGES3 AL-V30SGE 9
User Manual
Spacer
Spacer
1030
*
830
590
620
30
893
*
493200
*
200
*
200
*
30
200
*
200
*
TOP VIEW
Dimension and Installation Guide
vintec.com.au
1800 771 776
© 2018 Electrolux Home Products Pty Ltd ABN 51 004 762 341 VDIM_V30SGES3_DimSheet
35 Bottle Wine Cabinet
V30SGES3
*
V30 models are intended to be freestanding only.
At least 200mm of space is required above and
beside the cabinet as shown.
For complete installation instructions, please refer
to the user manual for this product.
NOTE: Illustrations not to scale.
All dimensions in millimetres.
SIDE VIEW
FRONT VIEW
Dimensional drawings:
