Operators guide
13
Operation
Unpacking
The head is supplied with a single telescopic pan bar, automatic wedge adaptor, four fixing
bolts and washers, and a Vinten spanner. A battery is already fitted for the level bubble and drag
knob illumination. Ensure that all items are unpacked prior to assembly of the head and
disposal of the packing materials.
After unpacking the head, and before carrying or lifting the head, ensure that:
The pan and tilt brakes ([3], [4]) are applied (see also ‘Pan and tilt brakes’ on page 17).
The centre lock [22] is engaged (see also ‘Locking the platform’ on page 16).
Mounting the head
The head can be mounted onto a heavy-duty tripod, pe
destal or suitable firm surface using the
four fixing bolts and washers. The four bolt fixing holes [15] on the underside of the head are
easily located using the bolt-hole position indicators [16]. Tighten the bolts using the Vinten
spanner supplied.
Always ensure that the head sits level on its support using the level bubble [7], which may be
illuminated by pressing the button located under the level bubble [8]. The light will extinguish
after approximately 15 seconds.
Pan bars
Fit the pan bar/s to the head and adjust the positio
n of each one before tightening the clamp
[24] on the mounting ([12], [25]). Adjust the length of the telescopic pan bar as required.
CAUTION! Do NOT lift the head by the platform. Only use the base and/or the
carrying handle to lift and carry the head.
NOTE: When mounted on Vinten Hawk or Teal pedestals, clearance between the head
and the pedestal weight tray prevents the use of 1.6 kg (5.5 lbs) and 0.47 kg (1.0
lbs) trim weights. Use alternative weights or fit the adaptor plate kit (part no.
3354-900SP) between the head and pedestal.
Warning!
1. Only mount the head onto equipment designed to support the
combined weight of the head and its maximum payload, 92.9 kg (204.8
lbs).
2. Before installing the head, hold a fixing bolt in position and check that
the threaded end does not project more than 20 mm (3/4 in.) above the
mounting face.
