Vinten Vision 6 - Brake Knob and Drag Control Knob Adjustment

16
Press the switch (12) and ensure that the level bubble (4) is lit for approximately 15 sec-
onds.
Brake knob and drag control knob adjustment
The pan and tilt brake and drag controls may require adjustment after prolonged use. These ad-
justments should be carried out by competent persons as detailed in the Maintenance Manual.
The Maintenance Manual may be obtained from Vinten Broadcast Limited or your local Vinten dis-
tributor or from our website at www.vinten.com.
Battery replacement
(14)
(14.1)
(2)
(12)
(7)
(4)
