20
To re-align the skid wheels:
Remove the column from the skid.
Engage the track lock (8) on each castor.
Remove two screws (7.1) from the foot support (7) on the fixed leg and remove the foot sup-
port.
Using a suitable spanner remove nut (8.1) (a spanner is available from Vinten Part No.
3319-900SP).
Apply Loctite 242 to the nut, re-install and tighten lightly.
Align the wheel on the fixed leg so that it runs parallel to the leg.
Using a suitable straight line on the studio floor, check that over a distance of 3.6 m (12 feet)
the deviation does not exceed 5 cm (2 in.). Re-adjust the wheel until this is achieved. If it
cannot be achieved, the wheels on the other two legs should be re-aligned.
Once the wheels have been correctly aligned, tighten nuts (8.1).
Install foot support (7) on each leg and secure with two screws (7.1).
Elimination of radial and side play on the elevation tube or top
stage
If excessive radial or side play is apparent on the elevation tube or top stage, refer to the appro-
priate section in the Maintenance Manual. This adjustment should be carried out by a competent
person.
