Vinten Vision Ped Plus - Operation; Assembling the Pedestal

9
Operation
Assembling the pedestal
Skid
Turn the skid upside-down, depress the leg locking plungers (13.1) and swing each folding leg
(13) out until the plungers lock the legs in the fully open position.
Set the skid on the ground on its wheels and apply the wheel brakes (9).
Skid
(9)
(13)
(13.1)
