Viofo A229 - Product Diagram; Inserting; Removing the Memory Card

Product Overview Product Overview
Product Diagram
Inserting / Removing the Memory Card
Rear Camera ( Optional )
Inserting the Memory Card
1)
Front Camera
2)
3 4
Push the memory card into the card slot until you hear a click,
with the card label facing the forward (away from the screen).
1 - Menu / Power On|Off
2
- Menu Up / Recording Start / Stop
3
- Menu Confirm / Video Protect /
Playback
4
- Menu Down /
Microphone Enable / Disable
5
- Wi-Fi On|Off
6
- Rear Camera Port
7
- Memory Card Slot
8
- External Microphone Port
1
- Power In / MicroSD Card
Reader Mode
2
- Reset Button
3
- Power Status Indicator
4
- Recording Status Indicator
5
- GPS Status Indicator
6
- Microphone Status Indicator
7
- Wi-Fi Status Indicator
7
6
5
4
3
Lens
Power In
USB Power Port
Mount
Lens
1
1
2
3
4
5
6
7
8
2
