Subject: Pristine Service Manual
Figure 21. Protecting nut
Figure 22. Labeling electrical wires Figure 23. Labeling ports
Figure 23A. the new type of on/off button Figure 23B. the Molex connection
6.8. Replacing the vacuum valve
- Disconnect the vacuum pipe (Figure 24) that is connected to the valve (Figure 25).
- Unscrew the nut that tight the valve to the system body and replace the valve.
