14
The color bleeds or visual effects appear unusual.
If your screen is all red or blue, or any colors disappear, check to see that the
cable is properly inserted. A loose connection can cause a bad signal.
Try connecting to another video source for comparison.
The screen appears to be scrolling, rolling, or moving unusually.
Check that your source frequency is within 144Hz.
Reconnect and ensure your video cable is secure.
The monitor needs cleaning
Make sure the monitor has been powered off before cleaning.
Always use soft, non-abrasive cloth when cleaning.
Use dry, non-abrasive cloth to gently remove debris or dust.
If necessary, lightly dampen a non-abrasive cloth with water and gently clean the
surface.
Never use alcohol or ammonia-based cleaning solutions.
Never spray liquid directly onto any part of the monitor.
The indicator light does not work
Check that the power is on.
Check that the power cable is connected and plugged in to a wall outlet.
Cannot plug and play.
Ensure the monitor is compatible with PC.
Ensure the graphics card is compatible with the monitor.
Check cable connectors for curved or damaged pins. Replace cables if needed.
Dim image
Adjust the brightness and contrast ratio.
Image jitter/moire pattern
Nearby electric equipment may interfere with the monitor.
Light indicator is on or flashing, but there is no image displayed on screen
Check that the monitor power is on.
Check that the graphics card is installed properly.
Check that the signal line connects securely with the monitor.
Check cable connectors for curved or damaged pins. Replace cables if needed.
Color shortage (red, green, or blue)
Inspect if the pins in the interface are curved.
Image position is not centered/the size is not right
Please adjust Clock or Auto setting.
Color difference (colors are not optimized)
Adjust RGB color or reset color temperature.
GNV27DB.indd 14 2020/3/26 18:39:16

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Viotek GNV27DB and is the answer not in the manual?

Viotek GNV27DB Specifications

General IconGeneral
Model NumberGNV27DB
LED IndicatorPower on: Blue (solid); Power saving: Blue (flashing)
Screen Size27’’
Curvature1500R
Viewing Angle178°(H) / 178°(V)
Aspect Ratio16:9
Resolution2560 x 1440p
BacklightE-LED
Typical Brightness250 cd/m2
Default Color Temp.6500
Color Gamut96% sRGB; 85% NTSC; DCI-P3 90%; Adobe RGB 83%
Contrast Ratio3000:1 (Static)
Dot Pitch0.2331 x 0.2331 mm
Refresh Rate144Hz
Response Time6ms (GTG)
PortsHDMI 2.0 x 1, HDMI 1.4 x 2, DP x 1, Audio out x 1
PowerDC 12V, Min 4A
Power ConsumptionTypical: 37W, Max: 58W; Standby <=0.5W
OSD LanguageEnglish, Español, Русский, Français, 한국, 日本語, 简体 中文
Usage Temp.32°F~95°F (operating), -4°F~140°F (storage), 10-90% RH (non-condensing)
Weight and Dimensions IconWeight and Dimensions
Tilt AngleForward 5°+ 2°; Backward 15°+ 2°
VESA Mounting75 x 75 mm
Dimension (With Stand)24.26 x 17.84 x 7.7 in (616.2 x 453.1 x 195.7mm)
Weight10.69 Ib. / 14.82 Ib. (incl. packaging)
