Event-ID Description
0xE804 CMD - Auto command: WEBPAGE recognized and successfully executed
0xE805 CMD - Auto command: LOAD_PROJECT recognized and successfully exe-
cuted
0xE806 CMD - Auto command: SAVE_PROJECT recognized and successfully exe-
cuted
0xE807 CMD - Auto command: FACTORY_RESET recognized and successfully
executed
0xE80B CMD - Auto command: DIAGBUF recognized and successfully executed
0xE80E CMD - Auto command: SET_NETWORK recognized and successfully exe-
cuted
0xE8FB CMD - Auto command: Error: Initialization of the Ethernet PG/OP channel
by means of SET_NETWORK is faulty
0xE8FC CMD - Auto command: Error: Some IP parameters missing in SET_NET-
WORK
0xE8FE CMD - Auto command: Error: CMD_START missing
0xE8FF CMD - Auto command: Error: Error while reading CMD file (memory card
error)
0xE901 Check sum error
0xEA00 Internal error - Please contact the VIPA Hotline!
0xEA01 Internal error - Please contact the VIPA Hotline!
0xEA02 SBUS: Internal error (internal plugged sub module not recognized)
ZInfo1: Internal slot
0xEA03 SBUS: Communication error CPU - PROFINET I/O controller:
ZInfo1: Slot
ZInfo2: Status
(0: OK, 1: ERROR, 2: BUSSY, 3: TIMEOUT, 4: LOCKED, 5: UNKNOWN)
0xEA04 SBUS: Multiple parametrization of a periphery address
ZInfo1: Periphery address
ZInfo2: Slot
ZInfo3: Data width
0xEA05 Internal error - Please contact the VIPA Hotline!
0xEA07 Internal error - Please contact the VIPA Hotline!
0xEA08 SBUS: Parametrized input data width unequal to plugged input data width
ZInfo1: Parametrized input data width
ZInfo2: Slot
ZInfo3: Input data width of the plugged module
VIPA System 300S CPU Deployment CPU 315-2AG13
VIPA specific diagnostic entries
HB140 | CPU | 315-2AG13 | GB | Rev. 14-40 75
