9.5 TIA Portal - Setting VIPA specific CPU parameters
Since the VIPA specific CPU parameters may be set, the installation
of the SPEEDBUS.GSD from VIPA in the hardware catalog is neces-
sary. The CPU may be configured in a PROFIBUS master system
and the appropriate parameters may be set after installation.
The GSD (Geräte-Stamm-Datei) is online available in the following
language versions. Further language versions are available on
inquires:
Name Language
SPEEDBUS.GSD german (default)
SPEEDBUS.GSG german
SPEEDBUS.GSE english
The GSD files may be found at www.vipa.com at the "Service" part.
The integration of the SPEEDBUS.GSD takes place with the following
proceeding:
1. Browse to www.vipa.com
2.
Click to ‘Service è Download è GSD- and EDS-Files
è Profibus’
3. Download the file Cx000023_Vxxx.
4. Extract the file to your work directory. The SPEEDBUS.GSD is
stored in the directory VIPA_System_300S.
5. Start the hardware configurator from Siemens.
6. Close every project.
7.
Select ‘Options è Install new GSD-file
’.
8. Navigate to the directory VIPA_System_300S and select
SPEEDBUS.GSD an.
ð
The SPEED7 CPUs and modules of the System 300S from
VIPA may now be found in the hardware catalog at PRO-
FIBUS-DP / Additional field devices / I/O /
VIPA_SPEEDBUS.
Thus, the VIPA components can be displayed, you have to
deactivate the "Filter" of the hardware catalog.
The embedding of the CPU 315-2AG13 happens by means of a vir-
tual PROFIBUS master system with the following approach:
1. Start the Siemens TIA Portal.
2. Configure in the Device configuration the according Siemens
CPU.
3. Configure your System 300 modules.
Requirements
Installation of the
SPEEDBUS.GSD
Proceeding
