Viper CEX410 - Technical specifications

8
Technical specifications （F20）
TECHNICAL SPECIFICATION
MODLE
CEX410-EU
VOLTAGE(V)
220~240
RATED POWER(W)
1850
FREQUENCY(Hz)
50/60
CORD(M/ FEET)
15M/50FEET
SOLUTION TANK (L/Gal)
35L/9Gal
RECOVERY TANK（L/Gal）
23L/6Gal
BRUSH MOTOR POWER(HP/W)
400 W
VACUUM MOTOR POWER(HP/W)
1200 W
VACUUM MOTOR STAGES AND TYPE
3-stage tangential
VACUUM MOTOR WATERLIFT (INCH/MM H2O)
3200 MMH2O
VACUUM MOTOR AIRFLOW(CFM,L/MIN)
85CFM,2407L/MIN
SOUND PRESSURE LEVEL(dBA)
70±3
PUMP CUT OFF PRESSURE(Bar/PSI)
8.3Bar/120PSI
PUMP WORKING PRESSURE 2 JETS(Bar/PSI)
5.9Bar/85PSI
PUMP WORKING PRESSURE 1 JET(Bar/PSI)
7.2Bar/105PSI
MACHINE SPRAY TIP MATERAIL
Brass
HAND TOOL SPRAY TIP MATERAIL
Stainless
SOLUTION FLOW 2 JETS (Gal/MIN ,L/MIN)
0.7Gal/MIN,2.8L/MIN
SOLUTION FLOW 1 JET (Gal/MIN ,L/MIN)
0.5Gal/MIN ,1.8L/MIN
BRUSH SPPED(RPM,Tr/Min)
1100RPM,11Tr/Min
VIBRATION
ah, w=0.74m/s²
CLEANING WIDTH (MM/INCH)
410 MM/16 INCH
NOZZLE WIDTH (MM/INCH)
460 MM/18 INCH
HAND TOOL WIDTH (MM/INCH)
121 MM/4.7 INCH
FLOOR TOOL WIDTH (MM/INCH)
254 MM/10 INCH
REAR WHEEL DIAMETER (MM/INCH)
254 MM/10 INCH
MACHINE NET WEIGHT (Lbs./KG)
121Lbs./55 KG
SHIPPING WEIGHT (Lbs./KG)
143Lbs./65 KG
MACHINE WEIGHT WITH SOLUTION WATER(Lbs./KG)
176Lbs./80 KG
MACHINE DIMENSION (L x W x H) (INCH/MM)
46 x20 x35 inches
1170 x 510 x 880 MM
SHIPPING DIMENSION (L x W x H) (INCH/MM)
35.5 x24 x36.5 inches
900 x 605 x 925 MM
HEIGHT WITHOUT HANDLE (INCH/MM)
28.5 inches/725 MM
