Viper VN2015 - Page 6

DIA
NO
PART
NUMBER
NO
REQ'D
1
VF30016 HANDLE RELEASE
1
2
VF30015 BOLT, HANDLE RELEASE
1
3
VF30018 WASHER, PLAIN
2
4
VF13503 NUT, LOCK, M8 X 5.7
1
5
VF30017 SCREW
1
6
VF30014 COVER, HOOK
1
7
VF45125 CORD, HANDLE
1
8
AS41901 PLUG PROTECTOR, SMALL MALE
1
9
VF50120A GROMMET
1
10
VF13504 NUT, LOCK, M10
1
11
VF30027 WASHER, PLAIN
1
12
VF14114 SCREW, M8 X 55
1
13
VF30013 HOOK, CORD
1
14
VF13493 SCREW, M6 X 10
1
15
AS112205 TUBE
1
16
VF44018 LEVER,SOLUTION
1
17
VV13667 SCREW, M4 X 8
2
18
VF48306 PIN
3
19
VF44016 LEVER, LEFT, SWITCH
1
20
VF45119 CORD, POWER SUPPLY
1
21
AS22009 STRAIN RELIEF, CORD
1
22
VF30108 GASKET, HANDLE, SOLUTION
1
23
VF14223 SCREW, M6 X 25
2
24
VF14218 SCREW, M6 X 45
2
25
VF13528 WASHER, TOOTH, M6
2
26
VF30102 REAR COVER, SWITCH HOUSING
1
27
VF99010C BREAKER, CIRCUIT, 17A
1
28
VF30109 COVER
1
29
GT13013 NUT, M4
3
30
VF48309 CLAMP BLOCK
1
31
VF44017 LEVER, RIGHT, SWITCH
1
32
VF44203 SWITCH ASSEMBLY
1
33
VF14212 SCREW, M3 X 25
2
34
VF13527 WASHER, TOOTH, M4
1
35
V
F13526 SCRE
W, M4 X 30
1
36
VF46705 SAFETY BUTTON
1
37
GV40218 SPRING, SAFETY BUTTON
1
38
VF48310 HANDLE GRIP
2
39
VF30101 FRONT COVER, SWITCH HOUSING
1
40
VF47035A "VIPER" LOGO
1
41
VF13604 WASHER, TOOTH, M5
4
42
VF14222 SCREW, M5 X 12
4
HANDLE GROUP FOR VN1715 & VN2015
DESCRIPTION
6
