Viper VN2015 - Page 9

DIA
NO
PART
NUMBER
NO
REQ'D
36
VF50119 WASHER, PLAIN, M12
2
37
VF14214 SCREW, M5 X 8
4
38
VF48202 WHEEL, 5"
2
39
VF40994 LABEL, READ MANUAL
1
40
VF44012 SCREW, M6 X 12.7
2
41
VF13666 WASHER, M6
2
42
VF13604 WASHER, LOCK, EXTERNAL TOOTH
4
43
YCQ10615 MOUNTING FRAME (BIG), CAPACITOR
1
44
AS41902 PLUG PROTECTOR, LARGE FEMALE
1
45
YCQ10414 CLEAR COVER
4
46
YCQ10416 CAPACITOR WRAP
2
47
VF999805
1
48
YLQ17507
4
49
50
VF999787 MOTOR, 110V, 1.5HP
1
51
VF44003 LABEL, MOTOR
1
52
VF41079 LABEL, VIPER
1
53
VF14222 SCREW, M5 X 12
3
54
VF30001 TOP COVER, MOTOR
1
55
VF30002 CLUTCH PLATE
1
56
VF47023
1
BASE GROUP FOR VN1715 & VN2015
BUMPER
BOLT ASSEMBLY
SEE #17 & #50
START CAPACITOR (BIG), 380-400F / 150V
DESCRIPTION
9
