Viper VN20DS - Page 8

DIA
NO
PART
NUMBER
DESCRIPTION
NO
REQ'D
BASE GROUP FOR VN20DS
1 GT13080 SCREW, M6 X 30 4
2 VF30011 CLAMP BLOCK, HANDLE 1
3 VF30026 AXLE 1
4 VF30020 BRACKET, LEFT HANDLE 1
5 VV20274 WASHER, PLAIN, M13 4
6 GV40235 CLAMP BLOCK, AXLE 2
7 VV13621 SCREW, SELF-TAPPING, ST, M5 X 20 4
8
VF13474A
WASHER PLAIN M5
4
8
VF13474A
WASHER
,
PLAIN
,
M5
4
9 VF13613 SCREW, M5 X 20 2
10 VA13474 SCREW, M5 X 16 5
11 VF13524 WASHER, PLAIN, M8 4
12 VF13519 WASHER, LOCK, M8 4
13 VF13618 SCREW, 5/16" - 2 1/4" 4
14 MF-VF002-4A SCREW, SELF-TAPPING, 1/4"-1" 6
15 MF-VF002-2 CLUTCH PLATE 1
16 MF-VF022 PAD HOLDER, 19" 1
17 VF30004 BUMPER, 20" 1
18 ZD48315 BEARING, #6002Z 1
19 ZD48200 SHAFT & ROTOR ASSEMBLY 1
20 VF30006 FRAME, 20" 1
21 VF99926-2 KIT, CARBON BRUSH 1
22 VF30008 ALUMINIUM BASE, MOTOR 1
23
VF40152
HOSE BARB
1
23
VF40152
HOSE
BARB
1
24 VF30019 BRACKET, HANDLE, RIGHT 1
25 VF13520 WASHER, LOCK 2
26 VF50119 WASHER, LOCK, M12 2
27 VF48202 WHEEL, 5" 2
28 VF13666 WASHER, M6 2
29 VF44012 SCREW, M6 X 12.7 2
30 ZD40225 BEARING, #6203Z 1
31
V
F999802B GEAR BOX 1
32 VF99021 COULPING 1
33 MT01102 SLEEVE 1
34 VF40990 LABEL, DUAL SPEED 1
35 VF41079 LABEL, VIPER 1
36 ZD48310 LABEL, MOTOR 1
37 ZD48000 MOTOR, DUAL SPEED 1
38
VA13473
SCREW, M4 X 16
1
38
VA13473
SCREW,
M4
X
16
1
39 VF44204 RECTIFIER 1
40 VA91347 SWITCH 1
41 ZD48309DY SHELL 1
42 VF13604 WASHER, TOOTH, M5 2
43 VF14214 SCREW, M5 X 8
2
44 GT13014 NUT, NYLON INSERT, M4
2
45 ZD48316A TRIAC ASSEMBLY
1
46
GT13048
SCREW M4 X 12
1
46
GT13048
SCREW
,
M4
X
12
1
47 VV67405 STRAIN RELIEF, CORD
1
48 VV67405-1A NUT
1
49 AS41902 PLUG PROTECTOR, LARGE, FEMALE
1
50 VF999794 CORD, MOTOR
1
51 ZD48330 KIT, SPEED ADJUSTMENT
1
52 VF40994 READ MANUAL LABEL
1
53
V
F40997 SERIAL TAG 1
8
