15 / 16INST-002766 / A plug´n´dose
7.2 Technical data
8 Disposal
plug´n´dose
Dimensions (h x w x d) 142x85x50 mm
Mounting 4 holes/5 mm, hole spacing 130x48 mm
Weight approx. 260 g
Voltage 24 V DC
Voltage of mains adapter 230 V/50/60 Hz
Consumption / rating 100 VA/2,7 A
Operating conditions +10 ° to +40 °C, air pressure 1 bar, relative humidity less
than 60% (non-condensing)
Storage conditions see page 8
Disassembly must be carried out by authorised maintenance staff.
Disposal may only be performed in line with the currently applicable, country-
specific specifications, standards and legislation.
Ensure environmentally friendly recycling of all materials.
Electrical parts must not be disposed of with household waste (2012/19/EU).
They must be taken to the collection points provided for this purpose or
disposed of in an environmentally appropriate way.
TECHNICAL SPECIFICATIONS / DISPOSAL
