TVD Series Multifunction Scale Operation Manual
-
1
-
1. INTRODUCTION
 The TVD series weighing scales are suitable for general weighing, check weighing,
simple parts counting, percent weighing ,accumulation and units conversion.
 Capacities from 3kg to 30kg (6lb to 60lb).
 Rechargeable battery provide up to 70 hours of continues use (with out backlight).
 Large 24mm LCD with white LED back light display.
 7 embossed membrane keys.
2. KEYS DESCRIPTION
Keys
Function
Function
in menu
Zero key
 Returns the display to zero
Confirm key
 To enter selected sub-menu in
settings
Tare key
 Used to perform a tare function,
Subtracts weights
Value increment key
 Used to change the selected
digit value
Scroll up key
 To change sub-menu in
parameter settings
Limit key
 Set the limits for tolerance checking
Right arrow key
 Used to move the digit to the right
 Scroll up menu in parameter
settings
Percent key
 Enters the percent weighing function
 To show weight, unit weight and
counts when counting parts
Left arrow key
 Used to move the digit to the left
 Scroll down menu in parameter
settings
Sampling key
 To switch from parts weighing to
parts counting
Clear key
 Used to reset parameters or
clear the total accumulated
values
Escape key
 To return to normal weighing
mode in other operating mode or
in parameter settings
Print key
 Used to send data to PC or printer
Accumulation key
 To add the value to the
accumulation memory, if the
accumulation function is not
automatic
Memory recall key

To
show the stored values from the
N.A
