INSTALLATION INSTRUCTIONS
1. TC2 VGAF3.5MM module
2. 3-Phono module
3. TC2-AMP3 module
4. Bare-wire speaker terminals
5. UK double gang surround
Connect as shown:
1. TC2 VGAF3.5MM module
2. 3-Phono module
3. DC Power
4. TC2-AMP3 module
5. Bare-wire speaker terminals
1
3
2
4
5
1
2
3
4
5
